Extreme Networks 10G-LR-SFP1 SFP+ Optical Transceiver

Technical SpecificationsModel：10G-LR-SFP1 Brand：Extreme Networks Product Type：Hot-pluggable SFP+ optical transceiver

Interface: LC duplex connector Rate: 10.3125Gbps 10GBASE-LR Wavelength: 1310nm Fiber type: Single mode fiber (SMF OS1/OS2 G.652) Max reach: 10km Diagnostic: DOM / DDM digital optical monitoring Operating voltage: 3.3V Transmit power: -8.2 ~ 0.5 dBm Receiver sensitivity: -14.4 dBm Max power consumption: ≤1W

Physical Parameter Weight：0.02kg Dimension：13.5mm(H) ×14.3mm(W) ×85mm(D) Operating temperature：0℃ ~ +70℃ Storage temperature：-40℃ ~ +85℃ Relative humidity：5%~95%, non-condensing

System compatibility

10G-LR-SFP1 is Extreme original 10G SFP+ singlemode transceiver. Compatible with Extreme Summit X440, X450a, VSP series switches equipped with SFP+ slots. Supports DOM real-time monitoring of optical power, temperature, supply voltage and laser bias current. Widely used for cross-building, campus backbone 10G single-mode fiber interconnection.

Function

10G-LR-SFP1 converts 10G electrical signal into optical signal for single-mode fiber transmission at 1310nm wavelength. DOM function can read transceiver working parameters in real time. It is used for 10km 10G point-to-point singlemode fiber connection for enterprise backbone network.

Installation

Wear ESD anti-static wrist strap. Insert the SFP+ module fully into the SFP+ port of switch. Connect LC singlemode fiber patch cord. Power on the equipment, verify module identification, DOM optical power reading and link status via switch CLI before commissioning.

InterfaceSFP+ gold finger, LC duplex fiber port, status indicator for Extreme Networks 10G-LR-SFP1.

FeatureOriginal Extreme 10G-LR-SFP1 SFP+ optical transceiver,1310nm wavelength,10km singlemode transmission,built-in DOM digital diagnostic function,hot-pluggable,LC duplex interface,low power consumption. This spare is designed for 10G long haul singlemode fiber interconnection for enterprise backbone.

DiagnosticModule undetected: Check gold finger cleanliness, SFP+ port health.

No optical link: Verify fiber polarity, singlemode fiber quality and peer transceiver matching.

Low transmit / receive optical power alarm: Dirty fiber endfaces or damaged singlemode fiber cables.

DOM read failure: Confirm switch firmware supports DOM function.

Over-temperature alarm: Check equipment cabinet ventilation and heat dissipation.

Product Brief10G-LR-SFP1 is Extreme Networks hot-pluggable SFP+ singlemode optical transceiver with 1310nm wavelength and max 10km transmission,classic spare part for enterprise backbone 10G singlemode fiber link overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
