Extreme Networks 5320-24T-8XE Ethernet Switch

Technical SpecificationsModel：5320-24T-8XE Brand：Extreme Networks Product Type：1RU Rack Mount Universal Enterprise Edge Switch

Port Configuration: 24 × 10/100/1000BASE-T RJ45 ports,autosensing full/half duplex,MACsec enabled 8 × 1/10G SFP+ empty uplink / stacking slots,MACsec capable,2 ports dedicated for stacking 1 × RJ45 serial console port 1 × USB-A port for firmware/configuration storage 1 × Micro-B USB console port

Software: Support dual operating system: Switch Engine / Fabric Engine, can be selected on deployment. Managed by ExtremeCloud IQ, ExtremeCloud IQ Site Engine or Platform ONE. Stacking: High-speed stacking within 5320 series under Switch Engine; stacking function unavailable on Fabric Engine mode. Power supply: Built-in fixed 90W AC PSU, input 90-132V/198-264V AC, 47~63Hz Operating temperature：0℃ ~ +50℃ Dimension: 44mm(H) ×440mm(W) ×280mm(D) Weight: 3.7kg

System compatibility

5320-24T-8XE belongs to Extreme 5320 universal edge switch family. SFP+ slots are compatible with Extreme 1G and 10G optical transceivers including SR, LR, BiDi modules. It supports cloud zero-touch provisioning or local on-prem management. Suitable for campus wiring closet, office building access network deployment. Stackable with other 5320 switches for larger access network expansion.

Function

5320-24T-8XE is universal enterprise edge switch. The 24 gigabit RJ45 ports provide wired access for PCs, printers and network terminals. 8 SFP+ slots offer high-speed 10G fiber uplink or stacking. Built-in MACsec for link-layer encryption. Supports VLAN, static routing, QoS, port security, storm control and network segmentation. Flexible OS selection adapts to traditional switched network or fabric architecture.

Installation

Mount the switch to standard 19-inch 1RU rack. Connect ground wire and AC power cord. Connect RJ45 cables to end devices. Insert SFP/SFP+ transceiver into SFP+ slot and connect fiber cable. Boot and select Switch Engine or Fabric Engine OS. Configure via console or ExtremeCloud IQ. Verify port negotiation, MACsec and stacking status after commissioning.

InterfaceGigabit RJ45 port, SFP+ transceiver slot, RJ45 serial console, USB-A, Micro-B USB console for Extreme Networks 5320-24T-8XE.

FeatureOriginal Extreme 5320-24T-8XE 1RU universal edge switch,24×Gigabit MACsec ports plus 8×10G SFP+ uplink/stacking slots,support dual operating system,cloud or on-prem management,built-in 90W power supply. This spare is designed for enterprise wiring closet gigabit access network.

DiagnosticDevice undetected: Check AC power input, power cord and earthing. RJ45 port no link: Verify cable quality, check auto-negotiation configuration. SFP+ port no link: Confirm transceiver compatibility, fiber polarity and port speed setting. Stacking failure: Ensure Switch Engine OS is active, inspect stacking cable and stacking port assignment. MACsec link down: Check MACsec key configuration on both ends of link. Over-temperature alarm: Inspect fan operation and rack ventilation.

Product Brief5320-24T-8XE is Extreme Networks universal edge gigabit switch with 24 MACsec-capable RJ45 ports and eight 10G SFP+ uplink/stacking slots,classic spare part for enterprise wiring closet access network replacement.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
