Extreme Networks 4220-4MW-8P-4X Ethernet Switch

Technical SpecificationsModel：4220-4MW-8P-4X Brand：Extreme Networks Product Type：1RU Rack Mount Layer 2 Ethernet Switch

Port Configuration: 4 × 1G/2.5G/5GBase-T RJ45 PoE++ ports (802.3bt, max 90W per port) 8 × 10/100/1000BASE-T RJ45 PoE+ ports (802.3at, max 30W per port) 4 × 1/10G SFP+ empty uplink / stacking ports 1 × 10/100/1000BASE-T out-of-band management port 1 × RJ45 serial console port 1 × USB-A port, 1 × Micro-B USB console port

Software: Switch Engine / Fabric Engine, support ExtremeCloud IQ zero-touch cloud management Stacking: Up to 8 units stacking within 4220 series; cross-series stacking with 4120/5000 series not supported Power input: 100-240Vac,50-60Hz,3.5A max, built-in fixed internal PSU Operating temperature：0℃ ~ +50℃ (max 3000m altitude), silent mode available below 35℃ Dimension: 44mm(H) ×440mm(W) ×261mm(D) Weight: 3.1kg

System compatibility

4220-4MW-8P-4X is Extreme Networks 4220 series cloud-managed multi-gigabit PoE access switch. The SFP+ slots are compatible with Extreme 1G /10G optical transceivers including SR, LR, BiDi modules. Supports local CLI management and ExtremeCloud IQ cloud management. Designed for high-power Wi-Fi 6 / Wi-Fi7 AP, PTZ camera and industrial PoE endpoints. It can stack with other 4220 switches to expand multi-gigabit PoE access network.

Function

4220-4MW-8P-4X is Layer2 multi-gigabit PoE access switch. 4 multi-gig ports deliver up to 90W PoE++ power for high-performance wireless access points, while 8 gigabit PoE+ ports supply power to regular IP cameras and IP phones. The four SFP+ slots provide high-speed 10G fiber uplink or stacking function. Supports zero-touch provisioning, VLAN, QoS, port security, storm control and network monitoring. Cloud management simplifies multi-site network deployment and rapid fault diagnosis.

Installation

Mount the switch into standard 19-inch 1RU equipment rack. Ensure 1RU free space above unit for silent cooling mode. Connect power cable and power on. Connect RJ45 terminals to PoE powered devices. Insert SFP/SFP+ transceiver into SFP+ slot and connect fiber cable. Configure via local console or ExtremeCloud IQ. Verify port speed negotiation, PoE power output and link status after commissioning.

InterfaceMulti-gig PoE++ RJ45 port, Gigabit PoE+ RJ45 port, SFP+ transceiver slot, out-of-band management port, serial console, USB port for Extreme Networks 4220-4MW-8P-4X.

FeatureOriginal Extreme 4220-4MW-8P-4X 1RU multi-gigabit PoE access switch,4×5G PoE++ plus 8×Gig PoE+ ports,4×10G SFP+ uplink slots,cloud zero-touch deployment,support stacking,built-in power supply. This spare is designed for enterprise edge network with high-power Wi-Fi AP deployment.

DiagnosticDevice undetected: Check power supply and power cable connection. PoE port no power: Verify PD device compatibility, check port PoE configuration and total system PoE power budget. Multi-gig port negotiation failure: Check Cat5e/Cat6 cable quality and length, reconfigure port speed mode. SFP+ port no link: Check transceiver model, fiber quality, fiber polarity and port speed configuration. Cloud offline: Verify out-of-band management network and DNS configuration. Over-temperature alarm: Check cabinet air circulation and fan running status.

Product Brief4220-4MW-8P-4X is Extreme Networks cloud managed Layer2 multi-gigabit PoE access switch with four 5G PoE++ and eight gigabit PoE+ ports plus four 10G SFP+ uplink slots,classic spare part for enterprise high-power Wi-Fi AP edge network replacement.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
