Extreme Networks AH-SR-2348P-NA Gigabit Stackable PoE+ Access Switch

Technical Specifications

Model：AH-SR-2348P-NA Brand：Extreme Networks Product Type: 1U rack mount Layer2/L3 stackable gigabit PoE+ enterprise access switch, NA North America SKU

Front Ports:

• 48 × 10/100/1000BASE-T RJ45 auto-sensing copper ports, IEEE802.3at PoE+, up to 30W per port

• 4 × 1G/10G SFP+ high-speed uplink slots for fiber or DAC cable

• 1 × USB 2.0 port for firmware upgrade

• 1 × RJ45 serial console port

• LED indicators for port link, activity, power and system fault alarm

Rear Panel Interfaces:

• 1 × OOB 10/100/1000BASE-T out-of-band management port

• Dual hot-swappable AC PSU slots

• Hot-swappable fan tray, front-to-back airflow

• Equipment grounding lug

Switching & Layer Features: Switch Fabric: 336 Gbps full duplex Forwarding Rate: 250 Mpps MAC Address Table: 128K entries Max Jumbo Frame: 9216 bytes VLAN: Up to 4094 802.1Q tagged VLAN Routing: IPv4 / IPv6 static & dynamic routing Security: 802.1X, MAC authentication, storm control, bidirectional ACL QoS: Hardware L2-L4 classification, 8 priority queues Stacking: Support stacking, multiple switches as one logical device Management: ExtremeXOS OS, SNMP, SSH, Web GUI, ExtremeCloud IQ

Power & Mechanical: Power Supply: Dual hot-swappable AC power modules PoE Total Budget: Max 1440W PoE+ power capacity Cooling: Hot-swappable fan tray, front-to-back airflow Operating temperature：0℃ ~ +50℃ Dimension: 442mm × 44mm × 380mm Weight: Approx 6.9 kg Mounting: Standard 19-inch 1U rack bracket

System compatibility

AH-SR-2348P-NA belongs to Extreme AH-SR series access switch family, NA North America region variant. Compatible with Extreme certified SFP/SFP+ transceivers and DAC/AOC cables. Supports stacking with other AH-SR series switches. Designed for North American enterprise campus, office and smart building PoE access network. Widely used to supply power for Wi-Fi AP, IP cameras and IP phones, spare for network upgrade and replacement.

Function

AH-SR-2348P-NA is 1U stackable gigabit PoE+ access switch manufactured by Extreme Networks. It supplies power and network connection via 48 PoE+ ports for wireless access points, IP surveillance cameras and VoIP phones. 4×10G SFP+ uplink ports provide high-speed fiber connection to aggregation or core switches. Stacking technology consolidates multiple physical switches to a single logical unit for simple centralized management. It supports IPv4/IPv6 routing, 802.1X port authentication, VLAN segmentation and hardware QoS. Redundant hot-swappable power and fan reduce single point of failure for stable 24/7 operation. Widely deployed for North America campus, retail and office PoE network spare replacement.

Installation

Follow ESD protection procedure. Mount switch to standard 19-inch rack. Install hot-swappable AC PSU and fan tray. Insert SFP+ transceivers or DAC cables for uplink. Use Cat5e/Cat6 copper cables for PoE terminals. Access serial console port for ExtremeXOS initial configuration, set VLAN, PoE allocation, stacking and QoS policy. Verify port connectivity and PoE power status after power-up.

Interface

48×PoE+ RJ45 ports,4×10G SFP+ uplink ports,USB port,serial console port,OOB management port,dual hot-swap PSU slots,hot-swap fan tray,status LED indicators for Extreme Networks AH-SR-2348P-NA.

Feature

Original Extreme Networks AH-SR-2348P-NA NA version PoE+ access switch,1U,48×1G PoE+ +4×10G SFP+ uplink,stacking capability,ExtremeXOS OS,hot swappable redundant power and fan. This spare unit is used for North American enterprise PoE access network maintenance and hardware replacement.

Diagnostic

Switch boot failure: Check AC power cord and PSU installation. PoE port no power: Verify PoE budget, power allocation and PD compatibility. 10G port link down: Confirm SFP+ transceiver/DAC compatibility and fiber connector cleanliness. Stack split fault: Check stacking cable and match ExtremeXOS firmware version. Temperature alarm: Inspect fan tray operation and rack air circulation.

Product BriefAH-SR-2348P-NA is Extreme Networks AH-SR series 1U stackable 48-port PoE+ gigabit access switch with quad 10G SFP+ uplink, North America SKU,classic spare for enterprise PoE access network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
