Extreme Networks X460-G2-24p-24hp Gigabit PoE+ Stackable Access Switch

Technical Specifications

Model：X460-G2-24p-24hp (460-G2-24P-24) Brand：Extreme Networks Product Type: 1U rack mount Layer2/L3 stackable high-density PoE+ enterprise edge access switch

Front Ports:

• 48 × 10/100/1000BASE-T RJ45 auto-sensing copper ports, IEEE802.3at PoE+ (30W per port)

• 4 × 1G/10G SFP+ high-speed uplink slots for fiber or DAC cable

• 1 × USB 2.0 port for firmware upgrade

• 1 × RJ45 serial console port

• LED indicators for port link, activity, power and system fault alarm

Rear Panel Interfaces:

• 1 × OOB 10/100/1000BASE-T out-of-band management port

• 1 × dedicated VIM versatile interface expansion slot

• 1 × timing clock module slot (PTP / SyncE)

• Dual hot-swappable PSU slots, AC/DC power module optional

• Hot-swappable fan tray, airflow direction selectable

Switching & Layer Features: Switch Fabric: 336 Gbps full duplex Forwarding Rate: 250 Mpps MAC Address Table: 128K entries Max Jumbo Frame: 9216 bytes VLAN: Up to 4094 802.1Q tagged VLAN Routing: IPv4 / IPv6 static & dynamic routing Security: 802.1X, MAC authentication, storm control, bidirectional ACL QoS: Hardware L2-L4 classification, 8 priority queues Stacking: SummitStack-V, up to 8 switches stacked as one logical unit Management: ExtremeXOS OS, SNMP, SSH, Web GUI, ExtremeCloud IQ

Power & Mechanical: Power Supply: Dual hot-swappable PoE AC power modules (sold separately) PoE Total Budget: Max 1440W full PoE+ power capacity Cooling: Hot-swappable fan tray, front-to-back / back-to-front airflow optional Operating temperature：0℃ ~ +50℃ Dimension: 442mm × 44mm × 380mm Weight: Approx 6.9 kg Mounting: Standard 19-inch 1U rack bracket

System compatibility

X460-G2-24p-24hp belongs to Extreme X460-G2 enterprise edge switch family. Compatible with VIM series uplink modules like VIM-4X10GE, Extreme certified SFP/SFP+ transceivers and DAC/AOC cables. Supports SummitStack-V stacking with other X460-G2 series switches. Designed for enterprise campus, smart building, factory PoE access network. Widely used for wireless AP, IP camera and IP phone network spare replacement.

Function

X460-G2-24p-24hp is high-density stackable gigabit PoE+ switch manufactured by Extreme Networks. It provides total 48 PoE+ copper ports to power indoor Wi-Fi AP, IP surveillance camera and IP telephone. Four 10G SFP+ ports offer high-speed fiber uplink to aggregation or core switch. Rear VIM slot supports extra high-speed interface expansion. SummitStack-V combines multiple physical switches into one logical device to simplify centralized network management. Built-in PTP timing function suits industrial and time-sensitive network. Modular PSU and fan support online hot-swap maintenance to improve network reliability. Widely deployed for large campus, office and smart building PoE network spare replacement.

Installation

Follow ESD protection procedure. Mount switch into standard 19-inch rack. Install hot-swap PSU and fan tray. Insert SFP+ transceivers or DAC cables for uplink. Connect Cat5e/Cat6 cables to PoE terminals. Access serial console port for ExtremeXOS initial configuration, set VLAN, PoE power allocation, stacking and QoS policy. Verify port link and PoE status after power-up.

Interface

48×PoE+ RJ45 ports,4×10G SFP+ uplink ports,USB port,serial console port,OOB management port,VIM expansion slot,timing clock slot,dual hot-swap PSU slots,hot-swap fan tray,status LED indicators for Extreme Networks X460-G2-24p-24hp.

Feature

Original Extreme Networks X460-G2-24p-24hp PoE+ access switch,1U,48×1G PoE+ +4×10G SFP+,VIM expansion,SummitStack-V stacking,ExtremeXOS OS,modular redundant power and fan,PTP timing support. This spare unit is used for enterprise campus PoE access network maintenance and hardware replacement.

Diagnostic

Switch fails to boot: Check AC power input and PSU fully seated. PoE port no power: Verify total PoE budget, power allocation and PD compatibility. 10G port link down: Confirm SFP+ transceiver/DAC compatibility and fiber cleanliness. Stack split fault: Check stacking cable and match ExtremeXOS firmware version. Over-temperature warning: Inspect fan tray running condition and rack air circulation.

Product BriefX460-G2-24p-24hp is Extreme Networks X460-G2 series 1U stackable 48-port PoE+ gigabit switch with quad 10G SFP+ uplink and VIM expansion slot, high PoE budget and PTP timing,classic spare for enterprise campus PoE access network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
