Extreme Networks C5G124-24 Enterasys C5 Stackable Gigabit Switch

Technical SpecificationsModel：C5G124-24 Brand：Extreme Networks (Legacy Enterasys) Product Type: 1U rack mount managed stackable enterprise gigabit Layer3 access switch

Front Ports:

• 24 × 10/100/1000BASE-T RJ45 gigabit copper ports

• 4 × Combo SFP ports (1G fiber or copper)

• 2 × dedicated 32G high-speed stacking ports

• RJ45 console port, reset button

• Per-port LED indicators and system health LED

Switch Fabric: 88 Gbps Forwarding Rate: 65 Mpps Max Jumbo Frame: 9216 bytes VLAN: Up to 1024 active VLANs, 802.1Q tagging Routing: Static routing, RIP, OSPF, multicast routing QoS: L2-L4 hardware classification, 8 priority queues per port Power Supply: Single internal AC power supply, support external RPS redundant power Software OS: Enterasys firmware Operating temperature：0℃ ~ +50℃ Weight: Approx 5.03 kg Mounting: Standard 19-inch 1U rack bracket

System compatibility

C5G124-24 belongs to Enterasys C5 stackable switch family. Can stack together with other C5 series switches via dedicated 32G stacking ports, maximum stack group of 8 units. Compatible with 1G SFP transceivers. Designed for enterprise campus wiring closet gigabit access layer deployment.

Function

C5G124-24 is non-PoE gigabit stackable Layer3 switch, original Enterasys C5 series. 24 gigabit copper ports connect PCs, printers and non-PoE terminal devices. Four combo SFP ports provide 1G fiber uplink to aggregation switches. Two dedicated high-speed stacking ports enable multiple switches to form a unified logical stack, simplifying management. It supports full L2 switching and basic L3 routing, 802.1X authentication, ACL, QoS and IGMP multicast. External RPS interface supports redundant backup power. Widely used for office, campus and hospital wired access network.

InstallationMount the switch into standard 19-inch rack. Connect AC power cord. Insert 1G SFP transceiver for fiber uplink if required. Use stacking cable to connect stack ports for multi-unit stacking. Access console port for initial configuration, set VLAN, routing and security policy. Verify port status and stack synchronization after power-up.

Interface24×GE RJ45 ports,4 combo SFP slots,2 dedicated stacking ports,RJ45 console port,reset button,RPS connector and LED indicators for Extreme Networks C5G124-24.

FeatureOriginal Extreme Networks C5G124-24 Enterasys C5 gigabit switch,24×1G copper ports +4 combo SFP,32G dedicated stacking,hardware L2/L3 forwarding,QoS and 802.1X security support. This spare switch is used for enterprise non-PoE wiring closet network maintenance and replacement.

DiagnosticSwitch fails to boot: Check AC power input, inspect power circuit and RPS connection. Copper port link down: Verify cable quality and auto-negotiation parameters. SFP port no link: Confirm SFP compatibility, clean fiber connector and check optical power. Stack split: Check stacking cable integrity, match firmware version of all stack members. High latency: Inspect QoS queue configuration and port broadcast storm.

Product BriefC5G124-24 is Extreme Enterasys C5 series 1U 24-port gigabit stackable Layer3 switch,classic spare for enterprise non-PoE wired access network.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
