Extreme Networks DS1404066-E5GS Passport 8692SF Fabric / CPU Module

Technical SpecificationsModel：DS1404066-E5GS Brand：Extreme Networks (Legacy Nortel / Passport) Product Type: Hot-swappable fabric + CPU controller module for ERS8600 modular chassis switch

Management Interfaces:

• 1 × 10/100BASE-TX RJ45 out-of-band management port

• 1 × DB9 serial console port

• Compact flash storage slot for firmware and configuration Module Core: Integrated SuperMezz enhanced CPU daughterboard Fabric Capacity: 256 Gbps switching fabric Memory: 256MB onboard RAM Max Jumbo Frame: 9216 bytes Routing: IPv4 / IPv6, static routing,OSPF,BGP,multicast routing High Availability: Sub-100ms failover between dual fabric/CPU modules Power Consumption: 85W typical Software OS: Passport / ERS firmware Operating temperature：0℃ ~ +40℃ Installation: Hot-swappable, insert into ERS8600 chassis slot Weight: Approx 3.3 kg

System compatibility

DS1404066-E5GS belongs to Nortel Passport 8692SF series fabric CPU card, later acquired by Extreme Networks. Designed exclusively for ERS8600 modular chassis. Chassis requires paired deployment of two fabric/CPU modules for redundancy. IPv6 and fast failover functions depend on installed SuperMezz daughterboard. Works with ERS8600 series I/O line cards.

Function

DS1404066-E5GS is combined switch fabric and main control processor module for ERS8600 enterprise core chassis. It serves as the central switching backplane and system brain of the chassis, responsible for route calculation, configuration management and cross-card data forwarding. The built-in SuperMezz daughterboard enables IPv6 protocol and ultra-fast sub-100ms failover. Dual redundant fabric/CPU cards can be deployed in one chassis to eliminate single point of failure. Hot-swappable design allows replacement without powering down the whole chassis. Widely used for large campus core network, enterprise aggregation chassis control and fabric redundancy upgrade.

InstallationFollow ESD protection procedure. Insert fabric CPU module into empty ERS8600 chassis slot and tighten captive retaining screws. Verify module recognition via console port. Upload matching firmware version, synchronize configuration between primary and standby fabric modules. Test failover function after installation.

InterfaceRJ45 OOB management port,DB9 serial console port,CF card slot,status LED indicators,backplane connector,captive retaining screws for Extreme Networks DS1404066-E5GS.

FeatureOriginal Extreme Networks DS1404066-E5GS Passport 8692SF fabric CPU module,256Gbps fabric bandwidth,with SuperMezz daughterboard,support IPv6 and sub-100ms failover,hot-swappable,dual redundant deployment for ERS8600 chassis. This spare module is used for ERS8600 core chassis fabric/controller maintenance and redundancy expansion.

DiagnosticModule undetected: Confirm module fully seated, tighten retaining screws, check compatible firmware version. Fabric failover abnormal: Verify both fabric cards have identical firmware and SuperMezz daughterboard installed. Configuration lost: Check compact flash health and storage status. Overheat alarm: Inspect chassis fan tray operation and internal airflow. Routing protocol failure: Confirm SuperMezz is activated for IPv6 functions.

Product BriefDS1404066-E5GS is Extreme Passport 8692SF fabric and CPU controller module for ERS8600 chassis,classic spare for enterprise core switch fabric and control plane redundancy.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
