Extreme Networks EC1404005-E6 10G SFP+ I/O Line Card

Technical SpecificationsModel:EC1404005-E6 Brand:Extreme Networks Product Type:Hot-swappable I/O line card / blade Compatible chassis:VSP 9000 modular chassis switch Ports:24 × SFP+ slots for 10G transceivers and 10G AOC/DAC cables Port speed:Wire-speed 10G per port Switching architecture:Non-blocking Minimum OS:ExtremeXOS Max modules per chassis:Depends on VSP9000 chassis slot quantity Operating temperature:0℃ ~ +40℃ Storage temperature:-40℃ ~ +70℃ Relative humidity:10%~90%, non-condensing Weight:2.4 kg

System compatibilityEC1404005-E6 is Extreme Networks VSP9024XT 10G fiber line card for VSP9000 series chassis. It works with VSP9000 management modules,fabric modules,power supplies and fan trays. Compatible with Extreme validated 10G SFP+ transceivers and direct attach copper / active optical cables. Widely used for data center aggregation and enterprise core 10G uplink spare replacement.

FunctionEC1404005-E6 provides wire-speed 10G SFP+ interfaces for VSP9000 chassis. It supports L2 switching, L3 routing, ACL, QoS and multicast. It reports port status,transceiver DDM data,module temperature and power consumption to chassis management module. Used to replace faulty high-density 10G I/O blades for VSP9000 chassis overhaul.

InstallationHot-swappable replacement. Insert EC1404005-E6 into empty slot of VSP9000 chassis. Tighten captive screws. Insert SFP+ transceivers or DAC/AOC cables. Verify module online status and transceiver DDM readings on ExtremeXOS before putting into production.

Interface24×SFP+ front panel slots,module status LEDs,ejector handles for Extreme Networks EC1404005-E6.

FeatureOriginal Extreme Networks VSP9000 series 24-port 10G SFP+ line card,hot-swappable,non-blocking wire-speed forwarding,transceiver DDM monitoring,ExtremeXOS OS,built-in self-diagnostic function. This spare supports high-density 10G server and inter-switch uplink deployment for data center aggregation networks.

DiagnosticModule not detected: check blade seating,captive screws and backplane contact. Port link down: verify SFP+ transceiver,fiber/DAC/AOC cable and port admin status. Transceiver no DDM data: confirm Extreme validated SFP+ transceiver. Over-temperature alarm: check chassis fan tray operation and airflow.

Product BriefEC1404005-E6 is Extreme Networks hot-swappable 24-port 10G SFP+ fiber line card for VSP9000 chassis,classic spare part for data center high-density 10G aggregation and uplink overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
