Extreme Networks G8X-SEALED Industrial Ethernet Switch

Technical SpecificationsModel: G8X-SEALED Brand: Extreme Networks Product Type: Sealed Industrial Managed Ethernet Switch Mounting: DIN rail / wall mount Operating temperature: -40℃ ~ +70℃ Storage temperature: -40℃ ~ +85℃ Relative humidity: 5%~95%, non-condensing Protection: IP40 sealed metal housing Ports:

• 8 × 10/100/1000BASE-T RJ45 ports

• 2 × SFP fiber uplink slots

• 1 × Console port Input power: DC 12~48V Weight: 1.3 kg

System compatibilityG8X-SEALED is Extreme Networks rugged sealed industrial managed switch. It runs ExtremeXOS, compatible with Extreme X440, X620, VSP series core switches. Designed for factory floor, transportation, power and outdoor cabinet industrial networks. Widely used for industrial network maintenance and spare replacement.

FunctionG8X-SEALED performs Layer2 switching and basic Layer3 routing for industrial field network. It supports VLAN, STP/RSTP, link aggregation, QoS, ACL and port security. The sealed housing protects internal circuit from dust, vibration and moisture. It monitors port link status, temperature and input DC voltage, triggers alarm for port down, over-temperature and power loss. It is used to replace defective industrial switches in harsh factory automation network.

InstallationCut off DC power before installation. Mount G8X-SEALED on DIN rail or wall bracket. Connect DC power supply, Ethernet cables and SFP transceivers into uplink slots. Configure ExtremeXOS, VLAN and ring redundancy parameters. Verify port link and network traffic before putting into production.

Interface8×RJ45 gigabit ports, 2×SFP slots, console port, DC power terminal, LED status indicators for Extreme Networks G8X-SEALED.

FeatureOriginal Extreme Networks G8X-SEALED sealed industrial switch, wide operating temperature range, IP40 sealed metal casing, anti-vibration and anti-shock, support industrial ring redundancy, ExtremeXOS OS, built-in self-diagnostic function. This spare supports factory automation and harsh site network maintenance.

DiagnosticNo power LED: check DC input power and power terminal wiring. Port link down: verify cable, connector, transceiver and port admin status. High temperature alarm: check enclosure ventilation and dust accumulation. Ring network interruption: check uplink SFP modules and ring protocol configuration.

Product BriefG8X-SEALED is Extreme Networks sealed rugged industrial managed gigabit switch with 8 copper ports and 2 SFP uplink slots. It is designed for harsh industrial environments, classic spare part for industrial automation network overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
