Extreme Networks SFP-10G-LRM SFP+ Optical Transceiver

Technical SpecificationsModel：SFP-10G-LRM Brand：Extreme Networks Product Type：Hot-pluggable SFP+ optical transceiver

Interface: LC duplex connector Rate: 10Gbps 10GBASE-LRM Wavelength: 1310nm Fiber type: Multimode fiber (MMF) Max reach: 220m Diagnostic: DDM / DOM digital optical monitoring Operating voltage: 3.3V Transmit power: -6.5 ~ 0.5 dBm Receiver sensitivity: -14.4 dBm

Physical Parameter Weight：0.02kg Dimension：13.5mm(H) ×14.3mm(W) ×85mm(D) Operating temperature：0℃ ~ +70℃ Storage temperature：-40℃ ~ +85℃ Relative humidity：5%~95%, non-condensing

System compatibility

SFP-10G-LRM is Extreme original 10G LRM SFP+ transceiver. Compatible with Extreme Summit, VSP series, 5420,5520 switches equipped with SFP+ slots. Supports DDM real-time monitoring of optical power, temperature and supply voltage. Widely used for short-distance multimode fiber interconnection inside data center, enterprise building horizontal 10G fiber link spare replacement.

Function

SFP-10G-LRM converts 10G electrical signal into optical signal for multimode fiber transmission. It supports DDM to monitor real-time working parameters of the optical module. It is used for 220m 10G point-to-point links over legacy multimode fiber in data center or campus building.

Installation

Wear ESD anti-static wrist strap. Insert the SFP+ module fully into the SFP+ port of switch. Connect LC multimode fiber patch cord. Power on the equipment, verify module identification, DDM optical power reading and link status via switch CLI. Confirm link transmission works normally before commissioning.

InterfaceSFP+ gold finger, LC duplex fiber port, status indicator for Extreme Networks SFP-10G-LRM.

FeatureOriginal Extreme 10GBASE-LRM SFP+ optical transceiver,1310nm wavelength,220m multimode transmission,built-in DDM digital diagnostic,hot-pluggable,LC duplex interface,low power consumption. This spare is designed for 10G short haul multimode fiber interconnection.

DiagnosticModule undetected: Check gold finger cleanliness and SFP+ port health. No optical link: Verify fiber polarity, multimode fiber quality and peer transceiver parameter matching. Low transmit / receive optical power alarm: Dirty fiber endfaces or damaged multimode fiber cables. DDM read failure: Confirm switch firmware supports DOM function. Over-temperature alarm: Check equipment cabinet ventilation and heat dissipation.

Product BriefSFP-10G-LRM is Extreme Networks 10GBASE-LRM hot-pluggable SFP+ multimode optical transceiver with 1310nm wavelength and 220m transmission distance,classic spare part for data center short-distance 10G multimode fiber link overhaul.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
