Extreme Networks SLX 9150-48Y-8C-AC-F Data Center Switch

Technical SpecificationsModel：9150-48Y-8C-AC-F (SLX9150-48Y-8C-AC-F) Brand：Extreme Networks Product Type: 2U rack mount high-density data center leaf switch, SLX9150 family

Front Ports:

• 48 × SFP28 slots, support 1G /10G /25G transceivers and DAC/AOC cables

• 8 × QSFP28 slots, support 40G /100G transceivers, breakout to 4×25G

• 1 × OOB 10/100/1000BASE-T RJ45 management port

• RJ45 serial console port

• USB port for firmware upgrade

• LED indicators for port speed, fan, PSU and system fault

Switching & Layer Features: Switching Capacity: 3.6 Tbps full duplex Forwarding Rate: 1320 Mpps Max Jumbo Frame: 9216 bytes VLAN: Up to 4094 802.1Q tagged VLAN, private VLAN Routing: IPv4/IPv6 static, OSPF, BGP, EVPN Virtual Network: EVPN-VXLAN overlay, VRF segmentation Security: ACL, storm control, DoS protection, FIPS 140-2 certified QoS: Hardware L2-L4 classification, 8 priority queues, DSCP marking ECMP: Up to 64 ECMP paths High Availability: MCT multi-chassis trunk, graceful restart

Power & Mechanical: Power Supply: Dual hot-swappable AC PSU, 1+1 redundant load sharing Cooling: 6 hot-swappable fan modules, front-to-back airflow (F suffix) Operating temperature：0℃ ~ +40℃ Mounting: Standard 19-inch 2U rack bracket Software OS: SLX-OS

System compatibility

SLX9150-48Y-8C-AC-F belongs to SLX9150 data center switch family. Compatible with SFP28 25G and QSFP28 100G optical modules, breakout cables. Works as leaf node in IP fabric, pairs with SLX9250/SLX9540 spine switches. Supports EVPN-VXLAN and MCT for fabric redundancy.

Function

SLX 9150-48Y-8C-AC-F is 2U high-density 25G leaf switch for modern data center IP fabric. 48×25G SFP28 ports connect servers and hypervisor hosts, 8×100G QSFP28 uplink ports interconnect to spine layer. EVPN-VXLAN enables multi-tenant virtual network segmentation. Dual redundant AC power supplies and hot-swappable fans guarantee non-stop operation. Front-to-back airflow design suits hot-aisle/cold-aisle data center cabinet layout. Supports FIPS 140-2 security compliance for financial and government data center. Widely deployed for virtualization cloud, high-performance computing and enterprise data center leaf layer.

InstallationFollow ESD protection procedure. Mount switch into standard 19-inch 2U rack. Install dual AC PSU and fan trays. Insert SFP28/QSFP28 transceivers or DAC cables. Access console port for initial SLX-OS configuration, enable EVPN-VXLAN, MCT and security policy. Verify fabric peering and port connectivity after power-up.

Interface48×SFP28 25G slots,8×QSFP28 100G slots,OOB management RJ45,serial console port,USB port,status LED indicators,dual PSU bays,fan trays for Extreme Networks SLX9150-48Y-8C-AC-F.

FeatureOriginal Extreme Networks SLX9150-48Y-8C-AC-F 2U data center leaf switch,48×25G SFP28 +8×100G QSFP28,dual redundant AC,front-to-back airflow,SLX-OS OS,support EVPN VXLAN and MCT. This spare switch is used for cloud and enterprise data center fabric leaf deployment and hardware replacement.

DiagnosticSwitch boot failure: Check AC power input, re-seat PSU and fan trays. 25G/100G port link down: Verify transceiver compatibility, check FEC configuration and cable quality. EVPN peer offline: Confirm underlay IP route and matching SLX-OS firmware version. MCT sync abnormal: Inspect inter-switch link and peer configuration. Overheat alarm: Check fan tray status and rack airflow.

Product BriefSLX9150-48Y-8C-AC-F is Extreme SLX9150 series 2U 48×25G +8×100G leaf switch with dual AC and front-to-back airflow,classic spare for modern data center IP fabric.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
