Extreme Networks VIM5-2Y Versatile Interface Module

Technical Specifications

Model：VIM5-2Y Brand：Extreme Networks Product Type: Non hot-swappable VIM5 versatile uplink interface module

Front Ports:

• 2 × SFP28 multi-speed slots, support 10G /25G operation

• Default speed:25G; configurable to 10G via CLI command

• LED indicators for port link, activity and module status

Software & Switching Features:

• Supported OS: ExtremeXOS / VOSS

• MAC Address Table: inherited from host switch

• Max Jumbo Frame:9216 bytes

• VLAN: Up to 4094 802.1Q tagged VLAN

• Supports L2 switching, L3 routing, ACL, storm control

• QoS: Hardware L2-L4 classification, multiple priority queues

Power & Mechanical:

• Power supplied by host switch

• Cooling: Depends on host switch internal fan system

• Operating temperature：0℃ ~ +40℃

• Form factor: dedicated VIM5 slot module

• Weight: Approx 0.38kg

System compatibility

VIM5-2Y belongs to Extreme VIM5 interface module family. Compatible with Extreme X465 series and VSP4900 series switches. Works with Extreme certified SFP28 optical transceivers, DAC and AOC cables. Used for adding high-speed uplink ports on enterprise and data center access/aggregation switches. Widely used for switch uplink expansion and spare replacement.

Function

VIM5-2Y is a versatile uplink expansion module designed for X465 and VSP4900 switches. It provides two SFP28 interfaces for high-speed fiber uplink. Users can set port speed between 10G and 25G via CLI without rebooting the switch. This module extends switch uplink bandwidth for connecting to core switches or server racks. Widely deployed for campus aggregation and data center top-of-rack network upgrade spare replacement.

Installation

Follow ESD protection procedure. Power off the host switch before installation, VIM5-2Y is not hot-swappable. Insert VIM5-2Y into dedicated VIM slot and fasten locking screws. Power the switch back on. Access CLI to set VIM speed (10G/25G). Insert SFP28 transceivers and fiber cables, configure VLAN and uplink policy. Verify port link status after configuration.

Interface

2×SFP28 slots,status LED indicators,golden edge connector for host switch VIM slot for Extreme Networks VIM5-2Y.

Feature

Original Extreme Networks VIM5-2Y VIM5 uplink module,2×10G/25G SFP28 ports,speed configurable via CLI,compatible with X465 and VSP4900 series switches. This spare unit is used for enterprise and data center switch high-speed uplink expansion and hardware maintenance.

Diagnostic

Module undetected: Confirm switch powered off during installation, re-seat module firmly. Port link down: Verify SFP28 transceiver compatibility, fiber cable integrity and connector cleanliness. Port speed cannot change: Check CLI command syntax and supported firmware version. Module fault alarm: Check host switch fan working status and ambient temperature.

Product BriefVIM5-2Y is Extreme Networks VIM5 series non hot-swappable versatile interface module with dual SFP28 ports, supports 10G/25G uplink for X465 and VSP4900 switches,classic spare for switch uplink expansion.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
