Extreme Networks 10GBASE-T-10GE SFP+ 10GBASE-T Copper Transceiver Module

Technical Specifications

Model：10GBASE-T-10GE Brand：Extreme Networks Compatible Product Type: SFP+ copper 10G transceiver module

Interface & Rate:

• Form Factor: SFP+

• Port: RJ45 copper connector

• Speed: 10GBASE-T, auto-negotiate 10G /1G /100M

• Transmission medium: Cat6a / Cat7 twisted pair cable

• Max distance: 100m with qualified Cat6a cable

• LED indicators for link and activity status

Electrical Features:

• Supply voltage: 3.3V

• Power consumption: Max 2.5W

• Compliance: IEEE 802.3an 10GBASE-T standard

Compatibility:

• Compatible with Extreme Networks SFP+ ports, Summit, X620, SLX, S-Series line cards

• Works on switches, firewalls, servers, network cards with SFP+ slots

• Supports ExtremeXOS, SLX-OS, EOS operating systems

Function

10GBASE-T-10GE is SFP+ copper transceiver module. It converts SFP+ electrical signal into 10GBASE-T copper signal via RJ45 port. It supports auto speed negotiation between 10G,1G and 100Mbps. It can utilize existing Cat6a copper cabling to deliver 10G Ethernet without fiber, flexible for server room and rack short distance interconnection. Widely used for network upgrade and spare replacement.

Installation

Follow ESD protection procedure. Insert the 10GBASE-T-10GE module into SFP+ slot of switch or network device. Lock the module. Plug Cat6a RJ45 patch cord into module RJ45 port. Power on device, verify link LED status. Configure port speed/auto negotiation on network OS if required.

Interface

SFP+ golden edge connector, RJ45 copper port, status LED indicators for 10GBASE-T-10GE transceiver.

Feature

10GBASE-T-10GE SFP+ copper transceiver,10GBASE-T IEEE standard,100m reach over Cat6a cable,speed auto-negotiation. This spare unit is used for short-range 10G copper network interconnection and hardware maintenance.

Diagnostic

Module not detected: Re-seat SFP+ module, check slot compatibility. Link down: Verify Cat6a cable quality, RJ45 crimping, cable length under 100m. Speed stuck at 1G: Confirm cable is Cat6a, check port auto negotiation setting. High packet loss: Check cable crosstalk, electromagnetic interference.

Product Brief10GBASE-T-10GE is SFP+ 10GBASE-T RJ45 copper transceiver, supports 10G/1G/100M auto negotiation,classic spare for short-distance 10G copper Ethernet connection.

DisclaimerAll parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and replacement.
