FANUC A06B-0127 Series Servo Motor

Technical Specifications

Model:A06B-0127 series

Brand:FANUC

Series:α6/2000

Rated power:1.0kW

Rated speed:2000rpm

Voltage:3-phase 140V

Frequency:133Hz

Encoder:Alpha A64 / A1000 encoder

Shaft:Optional taper shaft or straight shaft

Brake:Optional 24VDC electromagnetic holding brake

Insulation class:F

Protection class:IP67

Weight:13kg

Dimensions:130mm ×130mm ×220mm

Certification:CE

System compatibility:α series servo motor for FANUC 0iD / 0iMF CNC system,matched with αiSV servo amplifier,for CNC feed axes.

Function:Permanent magnet AC servo motor for CNC feed axis. It realizes closed-loop position and speed control via built-in alpha encoder. The encoder saves position data after power off,no homing required. Brake version locks shaft to prevent load dropping during power failure.

Installation:Flange mount,connect power cable,encoder cable and optional brake control cable to servo amplifier.

Interface:

‑3-phase power connector

‑Alpha encoder signal connector

‑24VDC brake power terminal(brake version)

‑Motor housing mounting flange

‑Taper or straight output shaft

Circuit feature:Built-in permanent magnet rotor,encoder sampling circuit,temperature detection circuit,optional brake coil drive circuit.

Feature:FANUC α series high performance servo motor,different suffix for shaft and brake configuration. High positioning accuracy,stable running. Common faults:encoder damage,coil burnout,bearing wear,brake pad aging. Complete suffix model number required for compatibility confirmation before replacement.

Diagnostic:Motor or encoder damage will trigger servo alarm,overload or position deviation alarm on CNC system. Brake failure may cause vertical axis drop risk for brake type.

Built‑in function

A06B-0127 α6/2000 servo motor provides stable high-precision closed-loop motion control for CNC feed axis,widely used for CNC spare part replacement. Brake model supports power-off holding function.

Product Brief

A06B-0127 belongs to FANUC α series servo motor spare parts family,1.0kW α6/2000 motor,multiple suffix variants with different shaft and brake options. Verify CNC system,servo amplifier and cable compatibility before ordering. Check winding insulation,encoder,bearing and brake function(brake version) during commissioning. Widely applied for CNC equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation.
