FANUC AIF01B Slave Interface Module P/N A03B-0819-C012

Technical Specifications

Model:A03B-0819-C012

Brand:FANUC

System compatibility:AIF01B slave interface module for FANUC 16i/18i/21i CNC system. It is plug-in module for A03B-0819 ABU05A/ABU10A I/O base rack. Used for I/O Link bus communication expansion between CNC host and external slave I/O station. Widely used for CNC lathes and vertical machining centers.

Function:I/O Link slave communication interface unit. Realizes data exchange between CNC main controller and distributed I/O slave stations. Equipped with JD1A/JD1B serial ports for I/O link daisy-chain wiring. Transmits digital input and output signals over I/O link bus.

Installation:Plug into slot of ABU series I/O base rack,bus backplane connection.

Interface:

‑Backplane bus connector for ABU rack

‑JD1A / JD1B I/O Link serial ports

‑24VDC power connector

‑Power and communication LED status indicators

Circuit feature:Serial communication drive circuit,signal isolation,surge protection,anti-interference for industrial cabinet environment.

Feature:Legacy discontinued FANUC communication module. Common faults:port damage,communication dropout,chip burnout. Confirm I/O base rack model before replacement.

Diagnostic:Faulty module triggers I/O link communication alarm on CNC screen;LED indicators show power and link status.

Power supply:24VDC

Protection class:IP20

Horizontal operating temperature:0℃ ~ +55℃

Storage temperature:-20℃ ~ +80℃

Relative humidity:5%‑90% non‑condensing

Vibration:Complies with machine tool industrial environmental requirement

Weight:0.35kg

Dimensions:130mm ×85mm ×30mm

Certification:CE,UL

Built‑in function

A03B-0819-C012 AIF01B interface module establishes I/O Link slave communication channel for FANUC CNC system,realizing data transmission between CNC host and remote I/O stations. Widely used for CNC machine control cabinet spare‑part replacement.

Product Brief

A03B-0819-C012 belongs to FANUC A03B series I/O spare parts family,AIF01B I/O Link slave communication module. Verify ABU base rack and CNC system version before ordering. Check I/O link cable and connector during commissioning. Widely applied for CNC equipment maintenance and renovation. ESD anti‑static protection shall be followed during installation.
