GE 36A167607CLG02 Control Circuit Board Unit

Module Feature

36A167607CLG02 is a GE industrial control printed circuit board. This board is designed for GE power drive systems, responsible for signal sampling, logic calculation and drive signal output. The PCB adopts industrial grade components with anti-interference and anti-vibration performance, adapting to long-term continuous operation in industrial control cabinet environment. It realizes closed-loop signal processing of current and voltage, cooperates with power components to complete drive control. Widely used in industrial variable speed drive, power conversion and heavy industry control equipment.

Working principle

The board collects voltage and current feedback signals from power loop, converts analog signals into digital signals through onboard AD chip. The main processor executes control algorithm and outputs driving pulse signals to power semiconductor devices. It also completes fault detection and protection signal transmission, once abnormal state is detected, it will quickly lock output to protect the whole power unit.

Onboard components

Main control MCU, A/D sampling chip, pulse output driving chip, signal isolation optocoupler, voltage and current sampling circuit, power supply regulation circuit, terminal connector group, status indicator LED.

LED indicators

Power LED, run LED, fault alarm LED.

Hardware self-diagnosis

Power supply abnormality, sampling circuit failure, communication timeout, output overcurrent detection, records fault code and running log.

Programming software

GE dedicated drive configuration software for parameter setting, signal monitoring and firmware upgrade.

Electrical & Process Parameters

Model:36A167607CLG02 Brand:GE Device type:Industrial Control PCB Board Power supply:24VDC / internal power rail Input:Current, voltage analog feedback signal Output:Drive pulse signal Communication:Internal bus Protection:Overcurrent, overvoltage, under voltage, hardware fault diagnosis

Mechanical & Structure

Mounting:Install inside GE drive cabinet Protection class:IP20 Housing:PCB without outer shell, fixed by screws

Environmental

Operating temperature:-20℃ ~ +60℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE,UL compliant Status: GE original industrial control circuit board for power drive system

Installation

Follow strict ESD protection procedure before handling. Cut off the whole equipment power supply before replacement. Fix PCB on the designated position of drive cabinet, insert each connector in place. Check all wiring and connector contacts, download and verify parameters before power-on commissioning.

Interface

Internal power connector, analog signal sampling terminals, pulse drive output connector, internal bus communication port.

Diagnostic

No drive output: PCB power supply fault or pulse circuit damage. Sampling abnormal: signal line loose or sampling component aging. Board no boot: internal power circuit failure.

Product Brief

GE 36A167607CLG02 industrial control printed circuit board, used in GE power drive system for signal sampling and drive logic control, installed inside drive cabinet.
