GE Fanuc IC200ALG264 Analog Input Module

Technical SpecificationsModel：IC200ALG264 Brand：GE Fanuc Product Type: Single-slot plug-in analog input module for VersaMax PLC backplane

Module Feature:Function: Convert analog signals from field transmitters,pressure,flow,temperature sensors to digital values for VersaMax CPU processing. Channel:16 single-ended analog input channels Signal Ranges:0~10V voltage, 0~20mA /4~20mA current Resolution:12-bit A/D conversion Isolation:Group isolation between field side and PLC logic side Input impedance:Voltage mode ≥100kΩ; Current mode max 200Ω LED indicators:Module OK, channel fault status indicators Hardware self-diagnosis:overrange alarm,open circuit and short circuit detection Backplane communication with VersaMax CPU Programming software:Proficy Machine Edition, VersaPro

Electrical ParametersBackplane supply:+5VDC, max 140mA Power consumption:Max 1.1W Field transmitter power supplied externally

Mechanical & Structure:Mounting:DIN rail installation, plug into VersaMax backplane Protection class:IP20 Dimension:110mm × 66.8mm × 50mm Weight:0.30kg

Environmental:Operating temperature:-20℃ ~ +60℃ Ambient humidity:5~95% non-condensing Certification:UL, CE Status:Manufacturer discontinued legacy spare part

System compatibilityIC200ALG264 belongs to GE Fanuc VersaMax I/O family. Compatible with VersaMax CPU, power supply and other I/O modules. Widely used for water treatment,packaging,HVAC and small process automation.

FunctionIC200ALG264 is GE Fanuc VersaMax high density 16-channel analog input module. It receives standard 4-20mA or 0-10V analog signals from field sensors. Group isolation blocks ground loop noise to protect PLC. Built-in channel fault detection helps locate broken or shorted field cables quickly. Compact DIN rail design saves cabinet installation space.

InstallationFollow lockout/tagout safety procedure before installation. Fully cut off VersaMax rack power. Insert IC200ALG264 into VersaMax backplane slot. Connect shielded sensor cables to terminal block. Configure channel signal range via programming software. Power on and verify analog reading.

InterfaceVersaMax backplane gold-edge connector,field analog input terminal block,on-board module / channel status LED indicators for GE Fanuc IC200ALG264.

DiagnosticNo analog reading:Check backplane power,external 24V sensor supply,channel range configuration and wiring. Signal jitter:Check cable shielding,ground connection and signal wire routing. Channel fault alarm:Overrange signal,open circuit or short circuit on field wiring.

Product BriefIC200ALG264 is GE Fanuc legacy VersaMax 16-channel 12-bit analog input module,supports standard voltage/current signal collection for process transmitters,discontinued I/O spare card.
