GE Fanuc IC695ETM001-CD Ethernet Communication Module

Technical SpecificationsModel：IC695ETM001-CD Brand：GE Fanuc Product Type: Single-slot plug-in Ethernet interface module for PACSystems RX3i universal backplane

Module Feature:Function: Provide industrial Ethernet communication for RX3i PACSystems controller,real-time data exchange between RX3i CPU,other PACSystems PLC,Series90 PLC,VersaMax,SCADA and HMI. Network ports:2 × shielded RJ45 10/100Base-TX,auto negotiation,auto MDI/MDIX,integrated internal switch,support daisy-chain topology Processor:200MHz onboard network coprocessor Communication protocols:SRTP, EGD Ethernet Global Data, Modbus TCP Service port:9-pin D-sub RS232 station manager port for configuration,diagnostic and firmware upgrade Single IP address for dual Ethernet ports Front panel reset button for module reboot and self-test LED indicators:Module OK, Link/Activity for each LAN port Hot-swap capable under qualified system configuration Hardware self-diagnosis for link fault,bus communication and module internal error Backplane data exchange with RX3i CPU

Electrical ParametersBackplane supply:+5VDC, power consumption 1.2A Serial baud rate:1200 ~115200 bps(RS232 station manager)

Mechanical & Structure:Mounting:Plug-in installation into RX3i universal backplane slot Protection class:IP20 Weight:0.51kg

Environmental:Operating temperature:0℃ ~ +60℃ Ambient humidity:5~95% non-condensing Certification:UL, CE approved Status:Manufacturer discontinued legacy spare part

System compatibility

IC695ETM001-CD belongs to GE Fanuc PACSystems RX3i family. Compatible with RX3i CPU, power supply, analog/discrete I/O modules. Widely used for power plant auxiliary,chemical,water treatment and factory automation SCADA interconnection.

Function

IC695ETM001-CD is dual-port Ethernet interface module manufactured by GE Fanuc for RX3i PACSystems. The built-in switch allows daisy-chain wiring without extra network switch. It supports EGD real-time shared data,SRTP programming communication and Modbus TCP client/server. RS232 station manager port is used for IP configuration and troubleshooting. Dual LAN LED shows link status and data activity.

Installation

Follow lockout/tagout safety procedure before installation. Fully cut off rack backplane power. Insert IC695ETM001-CD into vacant RX3i slot and lock retainer. Connect RJ45 network cable and RS232 service cable if needed. Set IP address via station manager tool,download hardware configuration,restore power and verify network link and data communication.

Interface

RX3i backplane gold-edge connector,dual RJ45 Ethernet ports,9pin D-sub RS232 station manager port,reset button,LAN and module status LED indicators for GE Fanuc IC695ETM001-CD.

Diagnostic

LAN link LED off:Check network cable,port negotiation and remote device power. EGD/Modbus data loss:Verify IP,subnet,firewall and PLC program configuration. Module OK LED off:Inspect backplane power,module seating or firmware corruption.

Product Brief

IC695ETM001-CD is GE Fanuc legacy PACSystems RX3i dual-port Ethernet module,with built-in switch,supports EGD and Modbus TCP for PLC and SCADA communication,discontinued rack network spare card.
