GE IC698CPE030‑GJ PACSystem RX7i High‑Performance CPU Module

Technical Specifications

Model：IC698CPE030‑GJ

Brand：GE Fanuc（Emerson Automation）

Product Type：PACSystem RX7i central processing unit module

Processor：600 MHz Intel Pentium‑M

Memory：64 MB battery‑backed RAM,64 MB non‑volatile Flash memory

I/O Capacity：32K bits discrete I/O,32K words analog I/O

Scan Speed：0.069 ms per 1000 Boolean contacts

Ethernet：2×10/100Mbps RJ45 ports,support SRTP,Modbus TCP,Ethernet Global Data

Serial Ports：RS‑232,RS‑485,Station Manager serial interface

Program Block：Max 512 program blocks,128KB per block

Programming Language：Ladder Diagram,Structured Text,Function Block Diagram,C language

Web Function：Web server & FTP,max 16 combined connections

Backplane：VME64 bus,install in slot1 of RX7i chassis

Power Consumption：+5VDC 3.4A,+12VDC 0.042A,‑12VDC 0.008A

Working Temperature：0℃ ~ +50℃ standard,0℃ ~ +60℃ with fan tray,non‑condensing

Storage Temperature：‑40℃ ~ +85℃

Humidity：5%‑95% non‑condensing

Application：Power plant process control,petrochemical automation,PACSystem RX7i system upgrade and spare‑part replacement.

Product Details

IC698CPE030‑GJ is a mid‑range high‑performance CPU module for GE PACSystem RX7i platform, it undertakes core tasks such as logic operation,program execution and system data management for the whole automation system.

This CPU module is installed in slot 1 of RX7i VME64 chassis. It is equipped with 600 MHz Pentium‑M processor, matched with 64 MB RAM and 64 MB Flash storage. Battery‑backed RAM ensures user data will not be lost when power is off, Flash stores configuration and firmware permanently.

It carries dual independent 10/100Mbps Ethernet ports and multiple serial interfaces. It supports multiple mainstream industrial protocols, realizes interconnection with HMI, upper computer and remote I/O stations. Built‑in web server and FTP function allow remote monitoring and file access.

The module complies with IEC‑61131‑3 standard, supports various programming languages. It can process up to 512 program blocks, satisfies complex process control requirements. It is compatible with Series 90‑70 I/O and standard VME64 modules, protecting legacy hardware investment during system renovation.

With battery‑backed real‑time clock, it provides accurate time stamp for alarm and event records. Widely applied in thermal power, petrochemical and heavy‑industry sites, used as replacement CPU spare‑part for PACSystem RX7i control racks
