Honeywell GLG5416 Industrial Limit Switch Unit

Module Feature

GLG5416 belongs to Honeywell MICRO SWITCH GLG series global plug‑in type limit switch. It adopts modular design, separate actuator head, switch body and contact block for easy replacement. Die‑cast metal shell, IP67 protection grade, built‑in single LED status indicator. The normally closed contact is positive opening type, which meets the safety circuit requirements. The installation dimension follows EN50041 standard. It is widely used for machine tool stroke limit, conveyor position detection, safety gate interlock, packaging equipment and outdoor mechanical position feedback.

Working principle

When the mechanical actuator head is touched and pushed by moving parts, the internal snap‑action contact block acts quickly. It switches the on/off state of the control circuit and feeds back the position signal to PLC or safety relay. The built‑in LED light shows whether the switch is powered on and triggered. Positive opening contact ensures reliable disconnection under fault conditions for safety interlock scenarios.

Onboard components

Die‑cast metal main housing, plug‑type contact block, snap‑action positive opening contact set, actuator head assembly, LED indicator circuit, internal wiring terminal, sealing gasket.

LED indicators

Front single LED indicator, display power supply and trigger status.

Hardware self‑diagnosis

No built‑in electronic self‑diagnosis. Upper controller judges fault by detecting circuit continuity; visual inspection to check shell crack, seal aging and actuator jamming.

Programming software

No configuration software, pure mechanical contact switch. Signal acquisition is completed by PLC or safety relay program.

Electrical & Process Parameters

Model:GLG5416 Brand:Honeywell Device type:Plug‑in Industrial Limit Switch Standard:EN50041 Protection:IP67 Housing:Die‑cast metal Contact:Positive opening NC contact, snap action Mounting hole:30 mm × 60 mm Certification:UL, CE, CCC Function:Mechanical travel limit, safety interlock, position signal feedback

Mechanical & Structure

Mounting:Bracket fixed installation, EN50041 standard hole spacing Protection class:IP67 Housing:Cast metal sealed enclosure

Environmental

Operating temperature:-25℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing Certification:UL / CE / CCC compliant Status:Original Honeywell MICRO SWITCH GLG series spare limit switch

Installation

Fix the switch on the fixed bracket according to EN50041 mounting hole. Adjust the trigger position to ensure the actuator head can be reliably touched by moving parts. Connect the control cable to the contact terminal, check the LED indication and signal switching action after power on.

Interface

Internal plug‑in contact block wiring interface, mechanical fixing hole.

Diagnostic

Signal cannot switch:Actuator stuck, contact ablation or wiring open circuit. LED no light:Power supply missing or indicator circuit damaged. Water ingress failure:Seal gasket aging, shell crack, lose IP67 protection.

Product Brief

Honeywell GLG5416 plug‑in limit switch, metal housing IP67, positive opening safety contact, with LED indication, EN50041 standard, used for industrial machinery stroke limit and safety interlock detection.
