Honeywell TV7-XTA0-0XH-0N-000 Valve Positioner

Feature & Principle

It is Honeywell TV7 series intelligent pneumatic valve positioner. It receives 4-20mA control signal from DCS system, compares the target valve opening with the actual valve position feedback signal, adjusts the output air pressure to the actuator, realizes closed-loop precise positioning of control valve. It supports HART protocol for remote parameter setting, self-diagnosis and valve characteristic configuration, with anti-vibration design, stable performance under complex process conditions.

Specifications

Model: TV7-XTA0-0XH-0N-000 Brand: Honeywell Series: TV7 Signal input: 4-20mA Communication: HART Action form: Single acting Air supply: 0.14~0.7MPa Mounting: According to IEC60534-6 standard Protection class: IP66 Applicable valve: Linear / rotary pneumatic control valve Application: Petrochemical, refinery, chemical plant flow, pressure and liquid level regulation Certification: CE, ATEX, IECEx

Components & Diagnostics

Main control circuit board, piezo pneumatic pilot valve, position feedback sensor, air channel assembly, local indicator. Common faults: position deviation, air leakage, HART communication offline, valve jitter, no air output.

Product Brief

TV7-XTA0-0XH-0N-000 smart valve positioner, Honeywell process control instrument spare widely used for regulating valve overhaul and replacement.
