Kollmorgen T126-0001 REV.P3 Motion Control Board Spare Part

Technical Specifications

Model:T126-0001 REV.P3

Brand:Kollmorgen

Part No:T126-0001 REV.P3

Product type:Motion control circuit board

Input voltage:24V DC

Dimension:230mm140mm30mm

Weight:0.52kg

Mounting:Chassis internal board slot mounting

Protection class:IP20

Operating temperature:0~40℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE

System compatibility

T126-0001 REV.P3 belongs to Kollmorgen legacy motion control accessory family,compatible with Kollmorgen SERVOSTAR and S200/S300 series servo drives,widely used in old CNC equipment,packaging machinery multi-axis motion control system.This is discontinued industrial spare part for equipment overhaul and maintenance.

Function

T126-0001 REV.P3 is revision P3 version motion control board.It is responsible for position signal acquisition,control logic operation and command transmission between motion controller and servo drives.It processes encoder/resolver feedback signals,output motion instruction to servo amplifiers,supports multi-axis synchronous motion control.

Installation

Install T126-0001 REV.P3 into device chassis board slot.Connect 24V DC power cable,servo feedback cable and control bus cable.Fasten connectors,complete shielding and grounding inspection before power-on test.

Interface

‑24V DC power terminal

‑Encoder / resolver feedback connector

‑Digital input and output terminal

‑Control signal port

‑Shield grounding terminal

Feature

T126-0001 REV.P3 is obsolete Kollmorgen spare part.Typical faults:onboard chip damage,capacitor aging,connector pin oxidation,track corrosion.Test 24V power supply and signal transmission before replacement.

Diagnostic

Board faults will trigger axis feedback loss,command transmission failure,axis synchronization error;machine axis no response,position deviation,intermittent alarm.

Built‑in function:Collect motion feedback signal,process control instruction,realize multi-axis servo synchronous control,as Kollmorgen legacy motion control board spare replacement.

Product Brief

T126-0001 REV.P3 is Kollmorgen revision P3 motion control board,24V DC power supply,used together with SERVOSTAR / S series servo drives for old CNC and automation equipment maintenance.Confirm board revision and signal definition before ordering.ESD protection required during handling and installation.
