Krohne EP0G0LEENN3ENH Radar Level Transmitter

Feature & Principle

It is Krohne OPTIFLEX 1300C series TDR guided wave radar level transmitter. Based on time domain reflectometry principle, high-frequency pulse signals travel along the probe and reflect at the medium surface to calculate distance. It is less affected by steam, foam, viscosity and dielectric variation. It supports HART communication for remote setup and diagnostic check. It can measure level and oil-water interface, and is widely used for chemical, petrochemical and oil separation tank monitoring.

Specifications

Model: EP0G0LEENN3ENH Brand: Krohne Series: OPTIFLEX 1300C Measurement: Liquid level, solid level, interface Output: 4-20mA, HART Probe type: Rod probe Pressure range: -1 ~ 42 barg Temperature range: -50 ~ +200℃ Ingress protection: IP66 / IP67 Certification: ATEX, IECEx, SIL2 optional Application: Petrochemical, oil-water separator, chemical storage tank, lubrication tank

Components & Diagnostics

Transmitter electronic head, LCD display, process connection, rod probe, sealing assembly, terminal housing. Common faults: probe scaling, echo signal loss, unstable reading, HART communication offline, zero drift.

Product Brief

EP0G0LEENN3ENH guided wave radar transmitter, Krohne OPTIFLEX 1300C level and interface measuring spare widely used for process tank instrument overhaul and replacement.
