Leuze CML720I-R20-950 Measuring Light Curtain Receiver Unit

Feature & Principle

This through-beam measuring light curtain receiver receives infrared light signal from transmitter. It judges the blocked beam position to calculate object height, width and contour data. Built-in signal processing unit, fast response, supports IO-Link for parameter setting and data upload, used for product sizing, sorting and material presence detection.

Specifications

Model: CML720I-R20-950 Brand: Leuze Series: CML720i Beam spacing: 20 mm Measuring range height: 950 mm Beam quantity: 48 beams Min detectable object: 30 mm Supply voltage: 18~30V DC Interface: IO-Link Protection: IP65 Certification: CE

Components & Diagnostics

Infrared receiving diode array, signal processing board, M12 connector, indicator LED and aluminum housing. Common faults: light pollution interference, signal loss, IO-Link communication abnormal, beam channel failure.

Product Brief

CML720I-R20-950 measuring light curtain receiver, Leuze sensor spare widely used for packaging machine, logistics sorting line and automated assembly dimension inspection.
