Meggitt 05445D Variable Reluctance Speed Sensor Unit

Feature & Principle

This passive reluctance sensor requires no external power supply. When gear teeth pass the probe tip, electromagnetic induction generates AC sine pulse signal. The signal frequency corresponds to shaft rotating speed, which is sent to turbine control system for speed indication, closed-loop regulation and overspeed trip protection.

Specifications

Model: 05445D Brand: Meggitt Type: Passive variable reluctance speed probe Output: Induced AC sine signal Application: Gas turbine, centrifugal compressor Working temperature: -55 ~ +200 ℃ Structure: Hermetically sealed stainless steel housing Mounting: Threaded installation Certification: Turbine high-reliability grade

Components & Diagnostics

Magnetic core, induction coil, stainless steel shell, integrated cable assembly. Common faults: coil open circuit, weak signal amplitude, intermittent signal loss, probe tip wear, cable insulation damage.

Product Brief

05445D speed probe, Meggitt high-reliability spare widely used for gas turbine shaft speed monitoring and protection loop.
