MODICON 7428-042-248096 Discrete Digital I/O Module

Technical Specifications

Model:7428-042-248096 Brand:MODICON(AEG) Product Type:Rack Mount Discrete Digital I/O Module Signal Type:24VDC digital input & output Backplane Bus:Modicon A series backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +60℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:0.8kg Dimension:260mm140mm30mm Protection:IP20

System compatibility

7428-042-248096 belongs to MODICON A series discrete I/O module. Compatible with MODICON A series CPU, backplane and rack power supply modules. It is used for field digital switching signal acquisition and control output. Suitable for chemical plant,water treatment,packaging machinery,conveyor line old AEG Modicon PLC system renovation and replacement as industrial spare part.

Function

7428-042-248096 discrete I/O module. It collects digital signals from field limit switches,proximity switches and push buttons,transmits signal status to MODICON PLC CPU. Meanwhile it receives control commands from CPU and outputs 24VDC switching signals to drive solenoid valves, relays and indicator lights. Built-in channel short-circuit protection and hardware self-diagnosis function. Each channel has LED status indicator. Widely used for digital on-off signal control in legacy AEG MODICON automation system, serving as reliable I/O spare part.

Installation

Cut off rack power before installation. Insert 7428-042-248096 module into MODICON A series backplane slot and lock the card. Check gold finger contact condition. Connect field sensor and actuator wiring to terminal block. Configure I/O address mapping,verify input reading and output action,complete function test before formal operation.

Interface

Backplane bus connector,field digital I/O terminal block,channel status and fault LED indicators for 7428-042-248096 MODICON discrete I/O module.

Feature

MODICON 7428-042-248096 digital I/O card,combined DI/DO design,24VDC signal,per-channel LED indication,short-circuit protection,standard single slot rack design,industrial anti-interference design. This discontinued legacy industrial spare part used for old AEG MODICON A series PLC digital signal control maintenance and replacement.

Diagnostic

Module not recognized: check rack power supply,backplane contact and module insertion for 7428-042-248096. Input no reading: inspect field sensor 24VDC power supply and wiring polarity. Channel no output: check PLC program logic,load wiring and terminal loose. Short circuit alarm: check field cable damage and actuator overload. Intermittent signal failure: check connector oxidation and electromagnetic interference.

Product Brief

7428-042-248096 is AEG MODICON A series discrete digital I/O module. It acquires field digital switching signals and outputs 24VDC on-off control signals for legacy MODICON PLC automation system,classic spare part for legacy industrial automation equipment overhaul.

Disclaimer

 All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
