MODICON 7628-000249627 Discrete I/O Module

Technical SpecificationsModel:7628-000249627 Brand:MODICON(AEG) Product Type:A Series Discrete I/O Module Signal Type:24VDC digital input & output Backplane Bus:Modicon A series backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +60℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:0.85kg Dimension:260mm140mm30mm Protection:IP20

System compatibility7628-000249627 belongs to MODICON A series discrete I/O module. Compatible with MODICON A series CPU, backplane and rack power supply modules. It is used for field digital switching signal collection and control output. Suitable for chemical plant,water treatment,packaging machinery,conveyor line old AEG Modicon PLC system maintenance and replacement as industrial spare part.

Function7628-000249627 discrete I/O module. It collects on-site digital switch signals such as proximity switches, limit switches and buttons, transmits signal status to MODICON PLC CPU. Meanwhile it receives control commands from CPU and outputs 24VDC switching signals to drive solenoid valves, relays and indicators. Built-in channel short-circuit protection and hardware self-diagnosis function. Each channel has LED status indicator. Widely used for digital on-off signal control in legacy MODICON A series automation system, serving as reliable I/O spare part.

InstallationCut off rack power and field load power before installation. Insert 7628-000249627 module into MODICON A series backplane slot and lock the card. Check gold finger contact condition. Connect field sensor and actuator wiring to terminal block. Configure I/O address mapping,verify input reading and output action,complete function test before formal operation.

InterfaceBackplane bus connector,field digital I/O terminal block,channel status and fault LED indicators for 7628-000249627 MODICON discrete I/O module.

FeatureMODICON 7628-000249627 digital I/O card,combined input & output design,per-channel LED indication,short-circuit protection,standard single slot rack design,industrial anti-interference design. This discontinued legacy industrial spare part used for old AEG MODICON A series PLC digital signal control maintenance and replacement.

DiagnosticModule not recognized: check rack power supply,backplane contact and module insertion for 7628-000249627. Input no reading: inspect field sensor power supply and wiring sequence. Channel no output: check PLC program logic,load power supply and terminal loose. Short circuit alarm: verify load cable damage and overcurrent. Intermittent signal failure: check connector oxidation and electromagnetic interference.

Product Brief7628-000249627 is AEG MODICON A series discrete I/O module. It acquires field digital switching signals and outputs on-off control signals for MODICON A series PLC automation system,classic spare part for legacy MODICON industrial automation equipment overhaul.
