MODICON AS-H810-1208 Discrete I/O Module

Technical Specifications

Model:AS-H810-1208 Brand:MODICON(Schneider/AEG) Product Type:984 Series Combined Digital Input & Output Module DI:12 channels 24VDC digital input DO:8 channels 24VDC digital output Backplane Bus:Modicon 984 backplane Mounting:Backplane rack slot mount Operating temperature:0℃ ~ +60℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:0.9kg Dimension:260mm140mm30mm Protection:IP20

System compatibility

AS-H810-1208 belongs to MODICON 984 series mixed digital I/O module. Compatible with MODICON 984 CPU and 984 rack backplane. It collects field digital switch signals and outputs switching control signals to actuators. Suitable for chemical plant,water treatment,packaging machinery,conveyor line legacy Modicon PLC system renovation and replacement as industrial spare part.

Function

AS-H810-1208 combined digital I/O module. It receives digital signals from field limit switches,proximity switches and push buttons,transmits input status to MODICON 984 PLC CPU. It receives control commands from CPU and outputs 24VDC switching signals to drive solenoid valves,relays and indicator lights. Built-in channel short-circuit protection and hardware self-diagnosis function. Each channel has LED status indicator. Widely used for digital on-off signal acquisition and control in legacy Modicon 984 automation system, serving as reliable discrete I/O spare part.

Installation

Cut off rack power before installation. Insert AS-H810-1208 module into MODICON 984 backplane slot and lock the card. Check gold finger contact condition. Connect field sensor and actuator wiring to terminal block. Configure I/O address mapping,verify input reading and output action,complete function test before formal operation.

Interface

Backplane bus connector,field digital I/O terminal block,channel status and fault LED indicators for AS-H810-1208 MODICON discrete I/O module.

Feature

MODICON AS-H810-1208 mixed digital I/O card,12DI+8DO integrated design,24VDC signal,per-channel LED indication,short-circuit protection,standard single slot rack design,industrial anti-interference design. This discontinued legacy industrial spare part used for old MODICON 984 PLC digital signal control maintenance and replacement.

Diagnostic

Module not recognized: check rack power supply,backplane contact and module insertion for AS-H810-1208. Input no reading: inspect field sensor 24VDC power supply and wiring polarity. Output no action: check PLC program logic,load wiring and output channel fault. Short circuit alarm: check field cable damage and actuator overload. Intermittent signal loss: check connector loose and electromagnetic interference.

Product Brief

AS-H810-1208 is MODICON 984 series mixed digital I/O module. It acquires field digital switching signals and outputs 24VDC on-off control signals for Modicon 984 PLC automation system,classic spare part for legacy MODICON industrial automation equipment overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
