NEMA 55/8BF Mechanical Dimension Unit

Module Feature

5-5/8 BF is NEMA standard imperial dimension notation. BF indicates bolt flange, 5-5/8 inch dimension commonly applied for NEMA motor C-face flange bolt circle or outer diameter. This standard is adopted by multiple motor manufacturers, ensures interchangeability of motors, gearboxes and pumps. This entry is only mechanical dimensional specification and contains no electrical components.

Working principle

Pure mechanical size specification without electrical function. It defines flange profile and bolt hole layout to guarantee alignment during flange coupling assembly. No electronic parts.

Onboard components

Not applicable, only dimension reference.

LED indicators

No built-in LED indicators.

Hardware self-diagnosis

Use caliper to verify actual dimension, inspect flatness and machining defects of flange surface.

Programming software

No dedicated programming software.

Electrical & Process Parameters

Model:5-5/8BF Brand:NEMA Standard (Non brand-specific) Device type:NEMA BF flange mechanical dimension Size:5-5/8 inch = 142.875 mm Function:Flange dimension reference for NEMA motor coupling Cooling:Not applicable Protection:Depends on complete motor assembly

Mechanical & Structure

Mounting:C-face flange mount Protection class:Depends on complete motor assembly Housing:Depends on matched motor housing

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:NEMA MG1 standard compliant Status: Universal NEMA BF flange dimension for NEMA frame motor mechanical assembly

Installation

Follow strict safety procedure before handling. Select pump or gear reducer flange conforming to NEMA 5-5/8BF dimension, ensure tolerance meets coupling assembly requirement.

Interface

BF flange interface, flange bolt holes.

Diagnostic

Dimension out of tolerance: machining error, causes coupling misalignment, vibration and premature bearing failure.

Product Brief

NEMA standard 5-5/8 inch BF flange dimension, 142.875mm conversion value, universal industry footprint for NEMA C-face motor flange coupling.
