RRTD-HI-IO-F-0 RTD Input Module Unit

Feature & Principle

This module collects resistance signal from PT100 RTD sensors, converts resistance value into temperature data through internal signal conditioning circuit. It communicates with upper control system, supports temperature alarm setting, used for motor winding, bearing and cabinet temperature monitoring.

Specifications

Model: RRTD-HI-IO-F-0 Signal type: PT100 RTD Power supply: 24VDC Mounting: DIN rail Protection: IP20 Certification: CE

Components & Diagnostics

Signal conditioning chip, communication circuit, terminal block and status LED. Common faults: temperature reading drift, channel failure, communication offline and power damage.

Product Brief

RRTD-HI-IO-F-0 temperature input module, industrial automation spare widely used for power cabinet, motor and bearing temperature monitoring.
