S005-4 Four Channel Analog Signal Isolator Unit

Feature & Principle

Four-channel analog signal isolator, receives 4-20mA field signal, isolates and retransmits signal to PLC system, eliminates ground loop interference and protects back-end control equipment.

Specifications

Model: S005-4 Brand: Generic industrial Isolation channels: 4 Input / Output: 4-20mA Power: 24V DC Mounting: DIN rail Installation Certification: CE

Components & Diagnostics

Signal isolation circuit board, status LED, wiring terminal block and isolation transformer. Common faults: signal drift, output no response, power supply abnormal.

Product Brief

S005-4 isolator module, 4-channel analog signal isolation spare widely used in process instrument and PLC control system.
