Siemens 10414460 CT X‑Ray Tube Assembly Unit

Module Feature

10414460 is Siemens CT scanner X‑ray tube assembly, a core medical imaging spare component. It generates X‑ray beam for computed tomography scanning. The listing status is “as‑is”, without guarantee of full working condition, belongs to second‑hand medical equipment spare part.

Working principle

High‑voltage power is applied inside the tube, electrons bombard the target material to produce X‑ray radiation. X‑rays penetrate human tissue, and the detector collects signal to reconstruct CT tomographic images.

Onboard components

X‑ray bulb, target anode assembly, high‑voltage interface, insulating oil housing, connecting mechanical flange.

LED indicators

No onboard LED indicators. Operation status judged by CT host system diagnostics.

Hardware self‑diagnosis

Check tube current, tube voltage, heat load, arcing fault via CT scanner host diagnostic software.

Programming software

Parameter diagnosis through CT scanner original medical system software.

Electrical & Process Parameters

Model:10414460 Brand:Siemens Device type:CT Scanner X‑Ray Tube Assembly Function:Generate X‑ray source for CT computed tomography imaging

Mechanical & Structure

Mounting:CT gantry internal mounting Protection class:Medical device integrated assembly Housing:Metal‑insulated enclosed housing

Environmental

Operating condition:Medical CT gantry inner environment Storage temperature:-40℃ ~ +65℃ Ambient humidity:5~95% non‑condensing Status:Second‑hand spare part, sold as‑is

Installation

Install inside CT scanner gantry, fix mechanical flange, connect high‑voltage cable, perform tube calibration and adjustment after replacement.

Interface

High‑voltage HV connector, mechanical mounting flange.

Diagnostic

Image artifacts:Tube aging / anode target ablation. Tube arc fault:Internal insulation breakdown. Unable to expose X‑ray:Filament burnout.

Product Brief

Siemens 10414460 X‑ray tube assembly, core radiation source spare component for CT medical scanner, supplied as‑is second‑hand unit.
