SOR 141-N Differential Pressure Switch

Feature & Principle

It is SOR 141 series mechanical differential pressure switch. It adopts diaphragm sensing structure, detects pressure difference between high pressure and low pressure ports. When differential pressure reaches the preset value, it triggers snap-action micro switch to realize on-off signal output. The set value can be adjusted on site without power supply. Stable repeatability, small dead band, some versions with nuclear 1E qualification, suitable for low differential pressure monitoring of minimum flow bypass and pipeline.

Specifications

Model: 141-N Brand: SOR Series: 141 Sensing element: Diaphragm Switch contact: SPDT Repeatability: ±1% FS Process medium: Air, water, non-corrosive fluid Mounting: Surface mounting Optional certification: Nuclear 1E qualified Application: Nuclear auxiliary system, boiler minimum flow, filter blockage, fan differential pressure monitoring Certification: CE, NQA-1 optional

Components & Diagnostics

Sensing diaphragm assembly, micro switch, adjustment screw, metal housing, wiring terminal. Common faults: diaphragm rupture and leakage, contact ablation, setpoint drift, no switch action.

Product Brief

141-N differential pressure switch, SOR mechanical pressure control spare widely used for power and nuclear process pipeline overhaul and replacement.
