Square D PFC34030G Bus Plug

Feature & Principle

It is Square D busway plug-in power tap unit. It is directly clamped and installed on the bus duct. Internal circuit breaker provides overload and short-circuit protection for the downstream load. It can quickly pick off power from the main busbar to supply power to single equipment or branch circuit. Equipped with grounding protection, reliable contact structure, easy installation and removal without cutting off the whole busway, widely used for flexible power distribution adjustment in workshop power system.

Specifications

Model: PFC34030G Brand: Square D (Schneider Electric) Rated current: 30A Rated voltage: 480V AC Phase: 3 phase Protection: Circuit breaker + ground protection Mounting: Plug on busway Lifecycle: Discontinued legacy spare Application: Factory workshop, production line, process equipment bus duct power distribution Certification: UL

Components & Diagnostics

Shell, built-in circuit breaker, bus contact jaw, grounding conductor, wiring terminal, operation handle. Common faults: contact overheating, poor contact, breaker tripping failure, grounding circuit open, handle stuck.

Product Brief

PFC34030G bus plug, Square D bus duct power tapping spare widely used for workshop power distribution cabinet overhaul and replacement.
