VIMEX VIMEX-001223 Automation Signal Module Unit

Module Feature

VIMEX-001223 is a general-purpose signal I/O module manufactured by VIMEX, designed for factory automation signal conditioning and switching control. It accepts discrete sensor inputs and provides relay or transistor outputs for actuator interlock. Standard supply voltage is 24V DC, with surge and reverse polarity protection built in. Terminal block wiring design for easy integration with PLC, sensors and solenoid valves. Compact DIN rail mounting form factor saves cabinet space. It includes overcurrent, short-circuit and internal temperature protection. Widely used for conveyor, packaging machine and general process auxiliary signal handling.

Working principle

Input terminals receive on/off or analog signals from field sensors. Internal signal conditioning circuit filters and isolates raw signals. The onboard logic circuit drives output relays or MOSFETs to switch load circuits. Status signals can be fed back to host control system for alarm and interlock logic.

Onboard componentsSignal conditioning PCB, input protection circuit, optocoupler isolation chip, output relay / MOSFET, power regulation circuit, terminal block assembly, status indicator LED array, plastic DIN rail housing.

LED indicatorsFront LEDs for power supply, input channel active, output activate and fault alarm.

Hardware self‑diagnosisSelf-check covers supply voltage out of range, output short circuit, overcurrent and internal chip fault. Fault state is indicated by dedicated LED.

Programming softwareNot programmable for most variants; fixed logic or simple DIP switch configuration.

Electrical & Process Parameters

Model:VIMEX-001223 Brand:VIMEX Device type:Industrial I/O Signal Module Power supply:24V DC Mounting:DIN rail Protection:IP40 Function:Field sensor signal acquisition and load switching control for automation equipment

Mechanical & StructureMounting:35mm DIN rail Protection class:IP40 Housing:Flame retardant plastic

EnvironmentalOperating temperature:-10℃ ~ +55℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non‑condensing Certification:CE compliant Status:VIMEX original automation spare

InstallationClip module onto standard DIN rail. Wire 24V DC power, sensor input and load output terminals. Set DIP switches if applicable. Verify input response and output switching before commissioning. Avoid heavy vibration and corrosive atmosphere.

Interface24V power terminals, digital/analog input terminals, output load terminals.

DiagnosticNo power LED: 24V supply missing, reversed polarity or blown internal fuse. Input no response: Sensor wiring break or input channel damage. Output cannot trigger: Overload, short-circuit lockout or output component failure.

Product BriefVIMEX VIMEX-001223 DIN rail I/O signal module, 24V DC powered, isolated signal input and relay output, IP40, used for factory automation sensor signal processing and actuator control.
