VMIC PCIE-5565PIORC-100000 Reflective Memory Board

Module Feature

VMIC PCIE-5565PIORC-100000 is a PCI Express form factor reflective memory interface board. It implements high-speed reflective memory network for deterministic real-time data synchronization among distributed nodes, featuring ultra-low transmission latency and hardware-level automatic data mirroring. Dedicated onboard controller handles data broadcast without heavy CPU overhead. Supports hardware interrupt signaling between nodes for event synchronization. Rugged PCB design with good EMC performance, widely used in real-time simulation, aerospace test, distributed motion control and industrial high-reliability embedded systems.

Working principle

Reflective memory creates shared memory space across all network nodes. When any node writes data to local onboard memory, hardware automatically broadcasts the data packet to all other reflective memory nodes over fiber or coax media, updating their local memory copies instantly. Host CPU accesses shared memory directly like local RAM. Hardware interrupts can be transmitted over the network for cross-node trigger and synchronization.

Onboard components

Reflective memory controller, high-speed serial transceiver, shared memory chips, PCIe bridge circuit, interrupt logic circuit, front panel status LED indicators, external fiber/coax network connector.

LED indicators

Front panel LED indicators for power supply, network link status, data activity and fault alarm.

Hardware self-diagnosis

Visual inspection of PCB, edge connector and solder joints; board ID register readback and firmware version check; memory read/write cyclic test; network link and multi-node communication verification; interrupt trigger function test.

Programming software

VMIC Reflective Memory device driver and API library, supporting VxWorks, Linux and Windows operating systems; configuration utility for node ID, memory size and interrupt mapping.

Electrical & Process Parameters

Model: PCIE-5565PIORC-100000 Device type: PCIe reflective memory interface module Bus standard: PCI Express Memory type: Reflective shared memory Control mode: Hardware auto mirroring, interrupt synchronization Power supply: +12 V / +3.3 V from PCIe slot Cooling: Convection cooling Protection: Over current, over voltage and ESD protection Mounting: Standard PCIe bracket mounting Protection class: Conformal coating optional

Mechanical & Structure

Mounting: Standard full-height PCIe board Protection class: PCB with optional conformal coating

Environmental

Operating temperature: -40℃ ~ +85℃ Ambient humidity: 5~95% non-condensing Certification: CE compliant Status: VMIC PCIe reflective memory module

Installation

Follow ESD safety procedure before handling. Shut down host PC completely and cut off power. Insert PCIE-5565PIORC-100000 into vacant PCIe slot and secure metal bracket with screw. Connect fiber or coaxial cable between reflective memory nodes. Configure unique node ID via software or hardware jumper. Install VMIC driver package and run multi-node communication test before formal operation.

Interface

PCIe gold finger edge connector, reflective memory fiber/coax network port, interrupt and status signal pins.

Diagnostic

Board undetected: poor PCIe slot contact, damaged edge connector, BIOS PCIe resource allocation error. Network link failure: dirty optical connector, wrong cable type, node ID conflict, power abnormality. Data corruption: unstable power supply, memory chip failure, temperature out of rated range. Interrupt malfunction: incorrect interrupt mapping, driver/firmware mismatch.

Product Brief

PCIE-5565PIORC-100000 VMIC PCIe reflective memory board,hardware accelerated real-time shared memory,for distributed simulation,aerospace test and high speed industrial real-time control systems.
