VMIC VMIACC-BT03 Rear Transition Panel

Module Feature

VMIACC-BT03 is a single-slot 6U VMEbus passive rear transition panel developed by VMIC (GE Fanuc / Abaco Systems),belonging to BT0X transition panel family. It mates with VMIVME-1184,VMIVME-344X and VMIVME-345X front VME I/O boards. This rear panel adopts dual 96-pin male connectors and bussed ground barrier terminal strips with lift-clamp terminals,accepts wire gauge 12–22 AWG. Fully passive hardware without any active semiconductor chips,only PCB trace routing for discrete digital and event sequence signals. Bussed ground plane optimizes common-mode noise suppression and simplifies shield wiring connection. It complies with ANSI/IEEE SWC TEST specification,fits standard EIA RS-310C 19-inch VME rack. Rugged Eurocard PCB with conformal coating,shock and vibration screened for power plant cabinet environment,widely used in gas/steam turbine sequence-of-event signal wiring,aerospace ground test bench and hardware-in-loop real-time simulation VME chassis.

Working principle

Discrete I/O and event signals from front VME I/O module pass through VME backplane to dual 96-pin connectors of VMIACC-BT03. Internal PCB traces route all signals to rear lift-clamp barrier terminals. Bussed ground plane unifies signal shielding reference. No power consumption and no signal processing,only pure passive wiring transition.

Onboard components

VME rear panel ejector hardware,dual 96-pin male connectors,bussed-ground lift-clamp barrier terminal block,passive copper trace network and continuous ground shield plane.

LED indicators

No LED indicators,completely passive hardware.

Hardware self-diagnosis

Visual inspection of PCB,components and solder joints;continuity test for all signal lines;96-pin connector pin contact test;shield and bussed ground continuity verification.

Programming software

No driver or software required,completely passive transition hardware.

Electrical & Process Parameters

Model: VMIACC-BT03 Brand: VMIC Device type: 6U VMEbus passive rear transition panel Bus standard: VME rear I/O signal routing via dual 96 pin mass connectors Wire range:12–22 AWG Terminal type:Lift-clamp barrier terminal strip with bussed ground Control mode: Passive wiring transition,bussed ground layout for EMI suppression,no active circuit Power supply: No external power needed Cooling: Convection cooling Protection: Continuous shield plane for noise reduction Mounting: Standard single-height 6U VME rear panel ejector locking Protection class: PCB with optional conformal coating

Mechanical & Structure

Mounting: Single-slot 6U VME Eurocard Protection class: PCB with optional conformal coating

Environmental

Operating temperature:0℃ ~ +70℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:20~80% non-condensing Certification: CE compliant Status: VMIC 6U VME dual 96-pin passive rear transition breakout panel for discrete I/O & SOE signal

Installation

Follow ESD safety procedure before handling.Fully power off VME chassis.Insert VMIACC-BT03 into rear slot aligned with matched front VME I/O board.Lock rear panel ejector latches.Strip and crimp 12–22 AWG field wires,secure conductors to lift-clamp barrier terminals.Power on chassis,run signal continuity check before commissioning.

Interface

Dual 96-pin mass connectors,rear bussed-ground lift-clamp barrier terminal block.

Diagnostic

Board undetected: not applicable for passive transition panel. Signal open circuit: cracked PCB trace or loose 96-pin connector contact. Ground noise interference: poor bussed-ground connection or unshielded field wiring. Terminal loose: lift-clamp not fully locked or improper wire stripping length.

Product Brief

VMIC VMIACC-BT03 single height 6U VME passive rear transition panel,equipped with dual 96-pin connectors and bussed-ground lift-clamp terminal block,designed for VMIVME-1184/344X/345X I/O modules,supports 12–22 AWG field wiring for turbine SOE signal collection and aerospace hardware-in-loop simulation VME racks.
