VMIC VMIPCI-5565-11 0000 Reflective Memory Board

Module Feature

VMIPCI-5565-11 0000 is a standard PCI bus fiber-optic reflective memory node board developed by VMIC (GE Fanuc / Abaco Systems). It belongs to classic 5565 reflective memory family,compatible with VMIVME-5565 and other RFM modules to build cross-platform mixed VME/PCI multi-node real-time network. Equipped with 128 MB onboard SDRAM with optional parity check function. The fiber communication speed reaches 2.12 Gbaud,effective payload bandwidth ranges from 43 MB/s for short packets up to 174 MB/s for 64-byte burst packets. Network supports ring topology or star topology with external hub,maximum 256 independent nodes on one reflective memory network. Any write operation to local onboard memory will be automatically broadcasted to all other nodes on the fiber ring via hardware without CPU software stack overhead. It supports programmable inter-node mailbox interrupt,one node can trigger event notification to a single target node or broadcast interrupt to all nodes. The board uses LC multimode fiber connector for optical signal transmission,providing complete galvanic isolation between different racks to eliminate ground potential shift and EMI interference. Built-in BIT diagnostic continuously monitors fiber link status,SDRAM integrity and parity error events;fault information can be read from onboard status registers. Rugged PCB with conformal coating,shock and vibration screened for harsh industrial environments,widely used in gas/steam turbine distributed control network,aerospace multi-chassis hardware-in-loop simulation and defense ground test bench.

Working principle

When PCI host writes data into local reflective memory space,onboard RFM FPGA automatically captures memory write events and broadcasts data packets over fiber optical transceiver to all nodes in the ring network. Every remote node receives optical data and synchronously updates its local SDRAM copy,application software directly accesses local memory for data reading,without complex network protocol processing. Mailbox interrupt registers transmit event trigger signals over fiber for multi-node task synchronization and alarm notification. BIT circuit continuously detects optical signal power,memory read/write errors and parity faults,and records error events inside status registers for host software polling. Optical transceiver converts electrical signals to optical signals and provides galvanic isolation to block common-mode surge noise between different chassis.

Onboard components

PCI bus interface FPGA,reflective memory controller,128 MB SDRAM memory bank with parity,fiber optical transceiver module,mailbox interrupt control logic,hardware broadcast circuit,BIT fault monitoring register bank,PCI gold finger edge connector,front-panel duplex LC fiber connectors,multi-status LED array.

LED indicators

Front panel LED indicators for fiber link lock and network fault alarm.

Hardware self-diagnosis

Visual inspection of PCB,components and solder joints;board ID register readback verification;onboard SDRAM full read/write & parity test;fiber loopback communication validation;PCI bus resource access test.

Programming software

VMIC reflective memory driver library and configuration utility,supports VxWorks,Linux and QNX real-time operating systems;software tool for memory mapping,node interrupt configuration and fault log reading.

Electrical & Process Parameters

Model: VMIPCI-5565-11 0000 Brand: VMIC Device type: PCI bus fiber optic reflective memory module Bus standard: 32 / 64 bit PCI Onboard Memory:128 MB SDRAM,parity function optional Fiber Spec:2.12 Gbaud,multimode fiber,LC duplex connector Network:Max 256 nodes,ring or star topology Transfer rate:43 ~174 MB/s,depends on packet size Control mode: PCI slot powered,hardware transparent memory mirroring,inter-node mailbox interrupt,fiber galvanic isolation,BIT real-time monitoring,ESD & surge protection Power supply: Powered by PCI motherboard slot Cooling: Convection cooling Protection: ESD clamping,optical over-power protection,parity error detection Mounting: Standard PCI bracket installation Protection class: PCB with optional conformal coating

Mechanical & Structure

Mounting: Standard full-height PCI board Protection class: PCB with optional conformal coating

Environmental

Operating temperature:0℃ ~ +65℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:20~80% non-condensing Certification: CE compliant Status: VMIC PCI fiber reflective memory node card with 128 MB memory

Installation

Follow ESD safety procedure before handling.Fully power off industrial PC.Insert VMIPCI-5565-11 0000 into vacant PCI slot and fasten bracket screw.Connect duplex LC multimode fiber to build reflective memory ring network.Assign unique node ID for every RFM board.Power on PC,load VMIC RFM driver,run BIT fiber link diagnostic before commissioning.

Interface

PCI gold finger edge connector,front-panel duplex LC fiber connector,interrupt and fault status register pins.

Diagnostic

Board undetected: PCI slot gold finger contamination,BIOS resource conflict or board hardware fault. Fiber link loss: dirty fiber end face,mismatched fiber type or optical transceiver damage. Parity error: SDRAM chip failure or memory timing mismatch. Inter-node interrupt failure: mailbox register misconfiguration or unstable fiber communication.

Product Brief

VMIC VMIPCI-5565-11 0000 PCI fiber reflective memory board,128 MB SDRAM hardware memory mirroring and programmable inter-node mailbox interrupt,supports up to 256 nodes,compatible with VMIC classic RFM series for mixed PCI/VME multi-node real-time network,suited for turbine distributed control and aerospace hardware-in-loop simulation systems.
