This optical incremental encoder adopts photoelectric scanning structure. The rotating code disc generates quadrature A/B pulses and Z reference pulse. The pulse signal is transmitted to PLC or drive controller for calculating rotation speed, rotation direction and index position. It has robust mechanical structure to resist vibration and shock in industrial sites.

Certification: CE

Code disc, photoelectric receiving board, bearing set, signal processing circuit, metal housing and connector. Common faults include missing pulses, zero pulse loss, signal jitter, bearing abnormal noise and connector poor contact.
