ABB 3ADT218437R0004 DCS400 DC Drive Main Control Board Unit
Feature & Principle
It is the core control board of DCS400 DC thyristor drive. It receives speed and current feedback signals, completes closed-loop PI regulation, generates trigger pulses for thyristor rectifier bridge. It supports parameter setting, fault recording and communication with upper controller, and provides overcurrent, overvoltage and overspeed protection logic.
SpecificationsModel: 3ADT218437R0004Brand: ABBApplicable Series: DCS400 DC driveFunction: Speed / current regulation, thyristor triggering, fault monitoringPower: Auxiliary power supplied by driveMounting: Plug-in slot inside converter cabinet
Certification: CE, IEC
Components & Diagnostics
Main CPU chip, pulse trigger circuit, AD sampling circuit, communication interface, status LED and backplane connector. Common faults: sampling deviation, trigger pulse loss, parameter loss, communication interruption and board burnout.
Product Brief3ADT218437R0004 control board, ABB DCS400 drive spare widely used for metallurgical rolling mill, paper machine and extruder DC motor speed regulation cabinet.
