Allen-Bradley 56C Motor Frame Unit

Module Feature

56C is NEMA standard small motor frame size from Allen-Bradley. It adopts stamped steel construction,compact size with C-face flange mounting design,without mounting feet. The frame holds stator stack,bearings and terminal box. Widely used on small pumps,gear reducers and material handling equipment.

Working principle

This is passive mechanical component. It supports stator core and bearing assembly,conducts heat generated by motor winding to ambient air. C-face flange allows direct coupling to reducers without extra adapter plate. No electronic components.

Onboard components

Steel frame body,C-face flange,heat dissipation ribs,bearing housing bore,terminal box mounting boss.

LED indicators

No built-in LED indicators.

Hardware self-diagnosis

Visual inspection for crack,deformation and rust; check bearing bore dimension and surface wear condition.

Programming software

No dedicated programming software.

Electrical & Process Parameters

Model:56C Brand:Allen-Bradley Device type:NEMA standard steel motor frame Frame size:56C Material:Steel Mount type:C-face flange mount Cooling:Natural convection cooling Function:Mechanical support and heat dissipation for small induction motor

Mechanical & Structure

Mounting:C-face flange mounting Protection class:Depends on complete motor assembly Housing:Stamped steel housing

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE,UL compliant Status: Allen-Bradley NEMA 56C compact motor frame for small industrial motor assembly

Installation

Follow strict safety procedure before handling.Assemble stator,bearings and end bells into frame.Install terminal box and couple motor flange to reducer with proper torque.

Interface

C-face flange interface,bearing bore,terminal box mounting interface.

Diagnostic

Frame deformation:overload mechanical impact. Bore wear:long time operation,causing abnormal bearing noise. Surface rust:storage in high humidity environment.

Product Brief

Allen-Bradley 56C NEMA steel motor frame,C-face flange mount compact structure,provides mechanical support and heat dissipation for small industrial induction motors matched to pumps and gearboxes.
