Allen-Bradley 184TC Motor Frame Unit

Module Feature

184TC is NEMA standard motor frame size from Allen-Bradley. It adopts cast iron construction with high mechanical rigidity and excellent heat dissipation. TC type supports both foot mounting and C-face flange mounting. The frame accommodates stator stack,bearings and terminal box assembly. Widely used for pumps,fans,conveyors and general industrial three-phase induction motors.

Working principle

This is passive mechanical structure. It supports stator core and bearing assembly,transfers heat from winding to ambient air. Combined foot and C-flange interface allows direct coupling to reducers and machinery without extra adapter plate. No electronic components.

Onboard components

Cast iron frame body,mounting feet,C-face flange,heat sink ribs,bearing housing bore,terminal box mounting boss.

LED indicators

No built-in LED indicators.

Hardware self-diagnosis

Visual inspection for casting crack,deformation and rust; check bearing bore dimensional tolerance and surface condition.

Programming software

No dedicated programming software.

Electrical & Process Parameters

Model:184TC Brand:Allen-Bradley Device type:NEMA standard cast iron motor frame Frame size:184TC Material:Cast iron Mount type:Foot mount + C-face flange mount Cooling:Natural convection cooling Function:Mechanical support and heat dissipation for 3-phase induction motor

Mechanical & Structure

Mounting:Foot / C-face flange mounting Protection class:Depends on complete motor assembly Housing:Cast iron housing

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE,UL compliant Status: Allen-Bradley NEMA 184TC motor frame for industrial three-phase induction motor assembly

Installation

Follow strict safety procedure before handling.Assemble stator,bearings and end bells into frame.Install terminal box and mount complete motor onto machine base with proper torque.

Interface

Foot mounting holes,C-face flange interface,bearing bore,terminal box mounting interface.

Diagnostic

Crack or casting defect:mechanical impact or material fatigue. Bore wear:long time running,will cause bearing abnormal noise. Surface rust:storage in high humidity environment.

Product Brief

Allen-Bradley 184TC NEMA cast iron motor frame,foot and C-face flange dual mounting design,provides mechanical support and heat dissipation for industrial three-phase induction motors for pumps,fans and conveyors.
