Allen-Bradley 145T Motor Frame Unit

Module Feature

145T is NEMA standard motor frame size from Allen-Bradley. The frame is cast iron construction with high mechanical rigidity and good heat dissipation performance. It is the mechanical housing for three-phase induction motor,provides mounting foot structure,bearing housing and heat dissipation ribs. Widely used for fan,pump,conveyor and general industrial motor equipment.

Working principle

Passive mechanical structure. The frame supports stator core and bearing assembly,conducts heat generated by motor winding to outside air,provides foot mounting interface to fix motor on machine base. No electronic components.

Onboard components

Cast iron frame body,mounting feet,heat sink ribs,bearing housing bore,terminal box mounting boss.

LED indicators

No built-in LED indicators.

Hardware self-diagnosis

Visual inspection for casting crack,deformation,surface rust; check dimensional tolerance and bearing bore condition.

Programming software

No dedicated programming software.

Electrical & Process Parameters

Model:145T Brand:Allen-Bradley Device type:NEMA standard cast iron motor frame Frame size:145T Material:Cast iron Cooling:Natural convection cooling Function:Mechanical support and heat dissipation for induction motor

Mechanical & Structure

Mounting:Foot mount Protection class:Depends on full motor assembly Housing:Cast iron housing

Environmental

Operating temperature:-10℃ ~ +40℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE,UL compliant Status: Allen-Bradley NEMA 145T motor frame for industrial three-phase induction motor assembly

Installation

Follow strict safety procedure before handling.Align frame with stator and bearing assembly,assemble end bells and terminal box.Mount complete motor onto equipment base with proper torque.

Interface

Foot mounting holes,bearing bore,terminal box mounting interface.

Diagnostic

Crack or casting defect:mechanical impact or material fatigue. Bore out of tolerance:wear,affects bearing running. Rust:long time storage in high humidity environment.

Product Brief

Allen-Bradley 145T NEMA cast iron motor frame,standard NEMA 145T footprint,provides mechanical support and heat dissipation for industrial three-phase induction motor used on fan,pump and conveyor.
