Allen‑Bradley 1336‑135105 Power Interface PCB Board

Technical Specifications

Model:1336‑135105

Brand:Rockwell Allen‑Bradley

Product Type:Power Interface PCB Board

Applicable Series:1336 PLUS,1336 PLUS II,1336 IMPACT series adjustable frequency ac drive

Function:Power signal sampling,over‑current detection,power stage signal transmission

Operating Temperature:0℃ ~ +40℃

Storage Temperature:-40℃ ~ +70℃

Product Details

1336‑135105 is power interface processing PCB board for Rockwell Allen‑Bradley 1336 series adjustable frequency ac drive. It undertakes power signal sampling,current detection and signal transmission between power unit and main control board,provides hardware‑level over‑current protection feedback for drive system. Adopts original circuit layout and complete terminal connectors,matches original installation dimension,supports direct plug‑in replacement without extra modification. It can solve drive faults such as false over‑current alarm,power signal loss and abnormal power unit feedback caused by board aging and circuit damage. ESD protection operation must be followed during installation. Widely used for on‑site maintenance of legacy fan,pump and conveyor automation equipment.

Remark:Legacy EOL spare component;original production discontinued;please confirm drive model compatibility before purchasing replacement.
