Allen‑Bradley 1336‑120859‑7‑01 Feedback Signal PCB Board

Technical Specifications

Model:1336‑120859‑7‑01

Brand:Rockwell Allen‑Bradley

Product Type:Feedback Signal PCB Board

Applicable Series:1336 PLUS,1336 PLUS II series adjustable frequency ac drive

Hardware Revision:7‑01

Function:Motor speed feedback signal acquisition,filtering and transmission

Operating Temperature:0℃ ~ +40℃

Storage Temperature:-40℃ ~ +70℃

Product Details

1336‑120859‑7‑01 is dedicated feedback signal processing PCB board for Rockwell Allen‑Bradley 1336 series adjustable frequency ac drive. It collects motor encoder speed feedback signal,completes signal filtering,shaping and transmission to main control board,ensures closed‑loop speed control accuracy of ac drive unit. Original circuit layout and pin definition,matches original mechanical installation dimension,supports direct plug‑in replacement without extra modification work. Effectively solves feedback signal loss,speed jitter,closed‑loop running abnormality faults caused by feedback board damage or aging. ESD protection operation must be implemented during installation process. Widely used for on‑site maintenance of legacy fan,pump and conveyor automation equipment.

Remark:Legacy EOL spare component;original production discontinued;please confirm drive model and hardware revision compatibility before purchasing replacement.
