Allen‑Bradley 1336‑135771 Digital Logic I/O PCB Board

Technical Specifications

Model:1336‑135771

Brand:Rockwell Allen‑Bradley

Product Type:Digital Logic I/O PCB Board

Applicable Series:1336 PLUS,1336 PLUS II,1336 IMPACT adjustable frequency AC drives

Core Function:Digital input signal reception,relay status output,optocoupler signal isolation,logic signal conversion

Signal Type:Dry‑contact digital input,relay contact output

Installation Method:Built‑in plug‑in installation

Operating Temperature:0℃ ~ +40℃

Storage Temperature:-40℃ ~ +70℃

Product Details

1336‑135771 is digital logic I/O processing PCB board for Allen‑Bradley 1336 series ac drive. It receives external dry‑contact commands such as start‑stop,forward/reverse signals, meanwhile outputs relay contact signals reflecting running status and fault alarm for external interlock devices.

It adopts optocoupler isolation design to separate field signals from drive internal logic circuit and restrain external interference. Matches original installation dimension and interface,supports direct replacement without extra modification. Solves typical faults including digital input no‑response,relay output failure and loss of external interlock function. ESD protection is required during installation.

Suitable for maintenance of legacy fan,pump and conveyor automation equipment.

Remark:Legacy EOL spare component;original production discontinued;please confirm drive compatibility before purchase.
