Allen‑Bradley 1336‑135775 Serial Communication Interface PCB Board

Technical Specifications

Model:1336‑135775

Brand:Rockwell Allen‑Bradley

Product Type:Serial Communication Interface PCB Board

Applicable Series:1336 PLUS,1336 PLUS II,1336 IMPACT adjustable frequency AC drives

Core Function:Serial protocol data conversion,upload drive operating data,receive remote control commands,communication signal isolation

Interface Type:Serial communication port

Installation Method:Built‑in plug‑in installation

Operating Temperature:0℃ ~ +40℃

Storage Temperature:-40℃ ~ +70℃

Product Details

1336‑135775 is serial communication interface processing PCB board for Allen‑Bradley 1336 series ac drive. It establishes serial data link between frequency converter and PLC or upper monitoring host. It uploads operating parameters, fault codes and real‑time status, and receives remote speed and start‑stop commands issued by upper controller.

Adopts signal isolation design to reduce interference brought by industrial field bus. Matches original installation dimension and interface,supports direct replacement without extra modification. Solves typical faults including communication drop‑off, no data feedback and failure of remote control. ESD protection is required during installation.

Suitable for maintenance of legacy fan,pump and conveyor automation equipment.

Remark:Legacy EOL spare component;original production discontinued;please confirm drive compatibility before purchase.
