Allen‑Bradley 1336‑140146 Main Control Logic PCB Board

Technical Specifications

Model:1336‑140146

Brand:Rockwell Allen‑Bradley

Product Type:Main Control Logic PCB Board

Applicable Series:1336 PLUS,1336 PLUS II,1336 IMPACT adjustable frequency AC drives

Core Function:Motor control algorithm operation,parameter storage,signal logic processing,fault diagnosis and system coordination

Installation Method:Built‑in plug‑in installation

Operating Temperature:0℃ ~ +40℃

Storage Temperature:-40℃ ~ +70℃

Product Details

1336‑140146 is the main control logic PCB board for Allen‑Bradley 1336 series ac drive. It acts as the core CPU unit of the frequency converter, running motor speed‑regulating algorithms, storing drive parameters, coordinating each sub‑board signal interaction and completing real‑time fault diagnosis.

It communicates with I/O boards, sampling boards and communication boards internally to realize complete drive functions. Matches original installation dimension and interface,supports direct replacement without extra modification. Solves typical faults including drive cannot initialize,parameter loss,random fault reporting and system operation crash. ESD protection is required during installation.

Suitable for maintenance of legacy fan,pump and conveyor automation equipment.

Remark:Legacy EOL spare component;original production discontinued;please confirm drive compatibility before purchase.
