AMAT 0100‑00689 VME PCB Power Module

Technical Specifications

Model：0100‑00689，FAB:0110‑00689

Brand：AMAT Applied Materials

Product Type：VME PCB power module assembly

Applicable System：AMAT Centura,P5000,Endura 200mm semiconductor process equipment

Supply Voltage：DC input from VME backplane

Interface：VME bus connector,on‑board power conversion components

Common Revision：Rev 01 and multiple hardware revisions available

Status Indicator：On‑board LED for power operating status

Built‑in Function：Local power regulation,DC‑DC power conversion,filtered low‑noise power output,power distribution for logic and analog circuit boards,over‑voltage protection

Working Temperature：0℃ ~ +50℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：VME card cage plug‑in installation

Weight：0.71kg

Product Brief:

0100‑00689 is legacy VME PCB power module manufactured by AMAT Applied Materials. It is installed inside VME electronics rack of Centura,P5000 and Endura wafer fabrication tools. It converts mainframe backplane DC power into stable filtered low‑noise voltages,supplies power for sensitive logic,communication and analog boards in card cage. Equipped with over‑voltage protection circuit and power status LED indicator. This is EOL discontinued spare part,widely used for maintenance and renovation of AMAT legacy 200mm wafer fabrication tools. Please confirm hardware revision and equipment compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
