AMAT ABX‑X302 High‑Voltage Diode Board Assembly

Technical Specifications

Model：ABX‑X302，Rev‑G

Brand：AMAT Applied Materials

Product Type：High‑voltage diode board assembly

Applicable System：AMAT Centura 200mm semiconductor process equipment

Supply Voltage：High‑voltage AC input

Interface：Multi‑pin high‑voltage power connectors

Common Revision：Rev‑G,multiple hardware revisions available

Status Indicator：No on‑board LED

Built‑in Function：High‑voltage AC‑DC rectification,transient surge suppression,high‑voltage circuit protection,energy‑loop rectifying for RF power supply subsystem

Working Temperature：0℃ ~ +50℃

Storage Temperature：‑20℃ ~ +70℃

Protection Class：IP20

Mounting：Chassis internal fixed installation

Weight：2.39kg

Product Brief:

ABX‑X302 is legacy high‑voltage diode board assembly manufactured by AMAT Applied Materials. It serves as high‑voltage rectifier circuit board for RF generator inside Centura wafer fabrication equipment. It completes high‑voltage AC‑DC rectification and absorbs transient surge to protect RF power subsystem. This is EOL discontinued spare part,widely used for maintenance and renovation of AMAT legacy 200mm wafer fabrication tools. Please confirm hardware revision and equipment compatibility before purchase. Strict ESD anti‑static protection shall be performed during installation.
